I made this to controller two 120V elements in my small batch system. The main PID controls up to a 2000W 120V element and has manual power control for boil level control. The second, smaller PID was used to control a 1500W element in my hot liquor tank. Includes one ½ NPT 1.5 long RTD probe which can be mounted in a tee off the kettle drain valve in a recirculating system. Other RTD temp probes are available from Auber in many configurations.
Each element output has its own separate power input. There is also a switched pump outlet on the 20A input circuit.
Other than the power cords, switches and SSR, everything came from Auber Instruments. Prices for individual components below.
SYL-1512 Universal 1/32 DIN PID Temperature Controller $35
SYL-2362 Universal 1/16 DIN PID Temperature Controller $41
½ NPT RTD Temp probe 1.5 long $35
Enclosure $53
Crydom 25A Dual SSR $45
Outlets $10
Power cords $30
Switches $6
Total $255 in parts.
This would be great for someone with a small batch system or if you need parts for an electric build.
I will include printed copies of the PID manuals.
Used only for testing and then I purchased a PicoBrew Zymatic for space saving and convenience.
