I don't think you need to be worried about back feeding. Both sides are providing the same 24 VAC, so there's nothing that will be damaged. Also, on both sides the back feed will just end at the open side of the switch or relay.
I am not worried about a darn thing anymore! Thanks to your help.
The way I designed the indicator lights into the circuit, they will get back-fed and simultaneously illuminate once the switch goes from off to either alternate state. So I will go with my idea to just feed DC to the control switch and keep the diodes as they are. Then I'll just take the clean 24VAC on the load side of my SSR since it is rated 24-240VAC on the load side.
