1.75 x 1.75 or 1 x 2 are you best bet
The stand looks great. Seriously.

Critiquing it, I would say the shelves are way too big for the kettles. Had it been built more within the actual needed dimension, 1 x 1 would have sufficed with only the cantilever needing braces.

But, it's built, it looks great and will do what it was intended to.



[nattron]

Here it is! I am just now after over 100 gallons brewed posting this picture. I get 80% efficiency on it.



[fermentinginpa]

Wow, that looks really tall. Great efficiency and nice rig!



[nattron]

Wow, that looks really tall. Great efficiency and nice rig!

Yea it us tall! But close to free. The tight is 2 department hanging racks. Found the outside of work.



[evandena]

Yea it us tall! But close to free. The tight is 2 department hanging racks. Found the outside of work.

Wouldn't want to stand under that HLT on a windy day



[CourtHouseBrewing]

Here it is! I am just now after over 100 gallons brewed posting this picture. I get 80% efficiency on it.

View attachment 58376

Needs outriggers or guy wires maybe.



[ldepaoli]

I went from this

To this



[dbrewski]

Since I live in a small lot house, senior living, I needed something that doesn't take up any precious space in the house or garage.

I love the ingenuity in this one. Way to go!



[dbrewski]

...and I just read thru every post on this thread. Do I get a prize now?



[evandena]

...and I just read thru every post on this thread. Do I get a prize now?

I did too. Made for a good week at work.



[Rivenin]

i think i've done it 2-3 times... i need a life haha



[jfrizzell]

...and I just read thru every post on this thread. Do I get a prize now?

Yes, now you get to build a brew stand! Get busy!



[HDIr0n]

This is my current setup

Wide Angle

DSC_0428 by HDIr0n, on Flickr

Closer up

Untitled by HDIr0n, on Flickr

Brewing a Moose Drool Clone today. Anyways about my rig, I am using a painters scaffolding until I build me a weldless wallace stand. I just upgraded to a bottom drain MLT, man this thing doesn't keep temp for crap compared to my old cooler. I am not sure if I want to do a flat brutus style, or a 1550 type rig.

-G



[jeepinjeepin]

Currently......



[SamuraiSquirrel]

Heres mine



[jimmayhugh]

The "Barney"



[OneHoppyGuy]

The "Barney"

You might want to load a lower resolution image. That one takes forever to load.



[Junkster]

Currently......

Hmmm.... looks like a 1.3 BBL brewery



[Millsteg]

Here's mine... Just finished



[krazydave]

Here's mine... Just finished

I like that Millsteg! looks like what I was planning on building. Do you by chance have the measurements for it?



[Millsteg]

I like that Millsteg! looks like what I was planning on building. Do you by chance have the measurements for it?

I don't remember the exact measurements off the top of my head but I used 2 inch square tubing, the mounts for each keggle and mash tun are 18 inch squares with 6 inch spacing between the top two. The total height is 24 inches I believe and the lower boil kettle sits 8 inches off the ground.

That's just off the top of my head but I can get the measurements for you exactly if you want.



[krazydave]

That's close enough! Thanks!



[evandena]

Here's mine with updated electrical. Might add a hard line for the water, otherwise it's done.

I can post plans if anyone is interested.



[capebeer]

Here's mine with updated electrical. Might add a hard line for the water, otherwise it's done.

I can post plans if anyone is interested.

Would love to see the plans if you have time to post....this will be my summer project up here in Ma!



[jumertens]

Here my upgrade from 5 to 10gal. The turkey fryer, former used as the boiler is now my HLT.



[evandena]

Would love to see the plans if you have time to post....this will be my summer project up here in Ma!

Sure, I'll try and get them up tonight



[j33per01]

Here's a pic of my Brutus clone which I just finished building last week. I haven't tested it yet.



[evandena]

<img src="https://www.homebrewtalk.com/attachment.php?attachmentid=59558"/>

<img src="https://www.homebrewtalk.com/attachment.php?attachmentid=59559"/>

Here's a pic of my Brutus clone which I just finished building last week. I haven't tested it yet.

Me gusta!



[metalpysko]



[Warrior]

New three tier stand hurricane burners work great on the Natural gas lines! The lowest stand is designed as a portable. I have a low pressure regulator so I can use it with a propane bottle.

Another option is scrap yard angle iron. A friend of mine welded my three tier design together and the used angle iron is quite cheap. I think mine was 2" angle iron. Here are some pics of the stand.



[akthor]

Pretty much all finished. I have a some hoses to make and a few odds and ends.



[garywebb96]

Scrap aluminum from a screen room tear out. The wheats in heat!



[jfrizzell]

Stay thirsty my friend.



[ButcherBrew]

Here my upgrade from 5 to 10gal. The turkey fryer, former used as the boiler is now my HLT.

Hi JU...

Do you have any plans to share? I am looking for a simple wood approach and yours definitely looks great.



[jumertens]

Hi JU...

Do you have any plans to share? I am looking for a simple wood approach and yours definitely looks great.

I made this pretty much around the equippment I had. Bought 4x6, the wood boards and designed while building. I was surprised how good it turned out



[cadwaladr]

Here is mine so far. still need all of the fittings, burners and pumps



[FScholle]

Here's my simple BIAB system. I use two 2000 W heating elements run from two different circuits. Pot is 40 qt.







This is the control box. One element is on/off only, the other onr regulated by a PWM circuit.



[Smashing]

Here's my "on the super cheap" rig.....

Pics show it mocked up. I thought I had some action pics but I guess I didn't take any. I know it's ugly but keep in mind this only cost me $6 to build!

I broke it in a couple of weeks ago and it helped to shave off about 2 hours from my brew day. It was so nice not to screw around with setting up and constant adjusting things.



[garbageman]

After viewing all the cool rigs this winter I made it my spring project to upgrade mine.

Nothing fancy, but has made brewing easier and allows for expansion. i just roll it out of the garage, hook up the water and brew.



[dbrewski]

After viewing all the cool rigs this winter I made it my spring project to upgrade mine.

Nothing fancy, but has made brewing easier and allows for expansion. i just roll it out of the garage, hook up the water and brew.

Nice rig I like the paint job. Quite the flame on that burner too!
