Strange LP Gas Surge

[accusedslacker]

Hopefully I have this in the correct section. I apologize if I missed it. I'm in the process of building a Brutus 10 kinda-clone. I have a propane bottle hooked up to the gas beam via a low pressure regulator. I turned on the bottle and charged the beam then I lit 1 burner. I get this gas surge about every other second the whole time. The regulator blows off then stops and the flame gets a little bigger then repeats. I can't smell any gas from the regulator but I can feel air flow coming out with my hand. If I plug the relief valve with my finger it slows down the surge but it still happens. Do you think I have a bad regulator or do I need a POL fitting instead of a QCC nut or am I off base all together? Thanks for your help in advance, Mike



[Copbrew133]

Beautiful stand. Do you have some shots of the regulator. It sounds like that may be the issue. I have seen some regulators that are low pressure, but considered secondary regs and are not intended to reduce the hundreds of psi out of the tank as a primary would. Im not saying that is the case but could be a possibility.



[Copbrew133]

Also which burners are those?



[accusedslacker]

Here's a picture of the regulator. The burners are just no name 6 inch burners. My buddy has the same with no problems.



[MI_Troll]

I would replace the regulator. It sounds like it could be sticking, which is resulting in a larger hysteresis than intended, hence the surge. Sometimes this can be resolved by tapping it with a large heavy object, but rebuilding/replacing is generally the better approach.



[Copbrew133]

Agreed, for the relatively smaller price of a reg you may completely solve the issue. If its a newer one I'd contact the folks where you bought it from and see if they'll make it right.



[The10mmKid]

Could it be the tank was overfilled and the regulator is dealing with slugs of liquid?

'da Kid



[accusedslacker]

You dudes rock. Cheers......



[accusedslacker]

Problem solved. I hooked up a new regulator and all is well.
