help building a DIY Drip tray

HomeBrewTalk.com - Beer, Wine, Mead, & Cider Brewing Discussion Community.

Help Support Homebrew Talk:

hopsoda

Well-Known Member
Joined
Dec 19, 2008
Messages
279
Reaction score
2
Location
Iowa
I'm looking for parts to make a cheap drip tray that will sit on top of a kegorator. does anyone have any ideas of what to use , I want stainless steel or a chrome , or black plastic. like a small grate in a 1" deep tray of some sort.
ideas?

or any cheap ones to buy? ... like under $20


McKBrew

Well-Known Member
Joined
Oct 19, 2006
Messages
8,190
Reaction score
39
Location
Hayden
Damn, BierMuncher was better with the links and pics. Same tray, great price.


McKBrew

Well-Known Member
Joined
Oct 19, 2006
Messages
8,190
Reaction score
39
Location
Hayden
I wonder how some SWMBO's would look standing next to that drip tray? I bet they'd sell more.


RC0032

Well-Known Member
Joined
Aug 3, 2008
Messages
1,124
Reaction score
17
Location
Chicago
That might just be one of the worst web sites I have ever visited...hows the service/ quality?

OP
hopsoda

hopsoda

Well-Known Member
Joined
Dec 19, 2008
Messages
279
Reaction score
2
Location
Iowa
Thanks didn't see that one, much cheaper


brewpal

Well-Known Member
Joined
Jan 22, 2008
Messages
113
Reaction score
15
Location
Salem, OR
+1 for Bar Products. Just stick the tray in the dishwasher as needed.



McKBrew

Well-Known Member
Joined
Oct 19, 2006
Messages
8,190
Reaction score
39
Location
Hayden
It is definitely one of the most poorly put together websites out there, but the service is fine.


Homercidal

Licensed Sensual Massage Therapist.
Lifetime Supporter
Joined
Feb 10, 2008
Messages
33,324
Reaction score
5,803
Location
Reed City, MI
I've seen a post where someone made drip trays out of a PVC Pipe cap with a shower drain cover for a screen. Pretty cheap and not bad looking. Maybe not as nice as these though.

OP
hopsoda

hopsoda

Well-Known Member
Joined
Dec 19, 2008
Messages
279
Reaction score
2
Location
Iowa
i really like DIY projects , gives me something to do that's use full,
I'm looking at the heater vent idea now , ill see what i come up with but
its hard to beat the price of that SS drip tray , finding quality materials for under $20 bucks to beat that price ... that's a challenge in itself.


maxbing

Well-Known Member
Joined
Nov 26, 2008
Messages
83
Reaction score
2
How are you guys attaching them to the side of the Kegorator?


McKBrew

Well-Known Member
Joined
Oct 19, 2006
Messages
8,190
Reaction score
39
Location
Hayden
How are you guys attaching them to the side of the Kegorator?
I tried some common store magnets which aren't working out (will not support the weight of a glass). I'm thinking of either strong hard-drive magnets, doublesided tape, or just gluing the damn thing on.


yermej

Well-Known Member
Joined
Jul 11, 2008
Messages
301
Reaction score
1
Location
Cape Girardeau, MO
So this looks great and all, but does anyone know where to get one to wrap around a draft tower?
ACU Metal Fab makes them for what seems to be a decent price, but they aren't $20.

I got this quote on 13 Jan 2009: 7" x 12" x 3/4" with 5" cut-out, removable perforated screen, center drain, s/s #4 brushed finish $86.22 ea

The 5" cut-out is for a 3" tower as it fits around the base rather than directly against the tower. If you want it with no drain, add $20. If you want it flush mount, add $20. So +$40 for no drain & flush mount. Polished finish would also add to the price, but I don't know how much.

Most other SS drip trays I've found have been $100+ and I've heard only good things about ACU (I got my tower from them), so they're probably the best bet. I was about to order one from them, but seeing this one for $20 is making me rethink dropping $120 on one.


humann_brewing

More Humann than human
Lifetime Supporter
Joined
Oct 6, 2008
Messages
15,506
Reaction score
355
Location
the sun
ACU Metal Fab makes them for what seems to be a decent price, but they aren't $20.

I got this quote on 13 Jan 2009: 7" x 12" x 3/4" with 5" cut-out, removable perforated screen, center drain, s/s #4 brushed finish $86.22 ea

The 5" cut-out is for a 3" tower as it fits around the base rather than directly against the tower. If you want it with no drain, add $20. If you want it flush mount, add $20. So +$40 for no drain & flush mount. Polished finish would also add to the price, but I don't know how much.

Most other SS drip trays I've found have been $100+ and I've heard only good things about ACU (I got my tower from them), so they're probably the best bet. I was about to order one from them, but seeing this one for $20 is making me rethink dropping $120 on one.
Actually I just ordered a tower from there too and got a quote for the drip pan too, but just couldn't bring myself to paying that much for what it is.

OP
hopsoda

hopsoda

Well-Known Member
Joined
Dec 19, 2008
Messages
279
Reaction score
2
Location
Iowa
OK , thanks all who posted it was allot of help. I ended up buying the one at the site above for the great price ... www.barproducts.com - great prices and great site buy the way.

But given the name of the post I thought it was rude not to build something.
When I was digging threw a bunch of computer equipment I found some of these.

A 80mm chrome CPU fan grill .... I think this will work and there dirt cheap.



doggage

Well-Known Member
Joined
Dec 7, 2008
Messages
462
Reaction score
6
Location
Fayetteville
i mounted mine with a couple stainless self-tapping screws. that was on the side of a kegerator, not a keezer, so i didn't have to worry about hitting any lines inside. not sure how i'd do it on a keezer, but i'm curious to find out!


chuggs

Well-Known Member
Joined
Jul 24, 2009
Messages
323
Reaction score
14
Location
Jupiter, FL
+1 for Bar Products!! I own two...

I'm still trying to design a fridge mount that I can drop the Drip Tray into. I'd like to be able to lift the whole thing out to run through the dishwasher... And it needs to stand off from the fridge just a little bit to make sure my stout faucet drips into it too...

I keep one with my Jockey Box...

Best price I've seen on Stainless Steel drip trays anywhere...


shoprat

New Member
Joined
Aug 12, 2007
Messages
2
Reaction score
0
Made mine free out of a peice of shelving from the fridge.


sorry it's sideways photbucket won't let me rotate it ...


Dwain

Well-Known Member
Joined
Feb 15, 2009
Messages
1,135
Reaction score
7
Location
Hill Country, TX
To attach them to a keezer, you can take some appropriate sized corner brackets and glue them to the keezer then set the drip tray on top of them. There are several epoxies out there that will handle the weight. I would definitely not drill into the keezer.
Just noticed Bobby's is mounted on a keezer. How did you mount yours. - Dwain


Bobby_M

Vendor and Brewer
HBT Sponsor
Joined
Aug 3, 2006
Messages
24,801
Reaction score
3,462
Location
Whitehouse Station
1 minute epoxy between the the corner brackets and the freezer (roughed up the finish a little first). Velcro between the tray and brackets for cleaning removal.
