New Rig

[monkeybuttbrewing]

here is my new rig still finishing the electronics, got it in trade from a guy that never finished it.



[H-ost]

You got all of that in a trade? What did you have to give up?



[monkeybuttbrewing]

I installed 80 lf. of cedar fence, labor only



[H-ost]

Gosh dang what a steal! If I could get a brew rig like that for 15 hours of work.....



[monkeybuttbrewing]

I'm about to change it up a bit though that stainless top, it has no venting for the burners,, and the hoses going through the top would probably melt. the guy built it and never brewed with it.
Rims system, 5k watt heater element running at 110v. march 809hs pump, 2x watlow 93 pid controllers, omega relays. The deal of the whole thing is that 130 qt. conical and the stand with the silicon band heater. he had a kid and never did the electronics on it. i'll convert it to herms system I think
and 17 hours. dug and poured new post also



[monkeybuttbrewing]

PID question. watlow 93aa wiring :/ is giving me issues their manual isnt exactly setup for a carpenter to read but for an engineer,

going out of the watlow into an omega ssr then to the heating element does anyone actually have eigh terminology, where I connect the post?

website for their manual http://www.watlow.com/downloads/en/manuals/93e_e_.pdf



[BigSally]

5000 watt heating element on 110 v ? Isn't that 45 amps?
I might be full of it,math is not my strong suit.
Also where's the pics of the afore mentioned conical(it's my new fetish)



[monkeybuttbrewing]

https://cdn.homebrewtalk.com/images/5/8/7/3/6/7717-6803.jpg
