keg shank dilemma

HomeBrewTalk.com - Beer, Wine, Mead, & Cider Brewing Discussion Community.

Help Support Homebrew Talk:

Joined
Jan 23, 2020
Messages
241
Reaction score
174
Location
duncannon
Alright so i have been wanting to make the switch to evabarrier and duotight. i built my 4 tap keezer years ago and my shanks have the 1/4 inch barb as part of the shank (not removable) well after spending the known amount on flow control intertaps and the the evabarrier hose and fittings it came to me.... well these duotight fittings are not going to just thread right on to my shanks. crap! not trying to be cheap but 4 new shanks at $20 a pop on top of what i just spent on the faucets (and a few used cornys) i really dont want to spend the money if i dont have to. can i safely remove the barb is my current train of thought. cut them off with a nice new blade then clean it up an be sure all shavings are removed, i think a cutting wheel would make more of a mess so scratch that. maybe bend it back and forth numerous times until weakens and snaps off. a pipe cutter maybe not strong enough to cut through it. any thoughts or input, other then the obvious of just sucking it up and spending the money to do it right. thanks in advance for any suggestions.


garzlok

Well-Known Member
Joined
Aug 19, 2012
Messages
360
Reaction score
221
Location
Dacula
So....I just went through this same dilemma. The answer is yes, you can cut off the barbs. I cut off the elbow barbs to 3 shanks. The problem, if not careful, you can create a leaker. 1 of my 3 shanks leaked (i nipped the back edge)

Sooo...I ended up buying 3 new shanks without a barb or tailpiece. (Checkout RiteBrew.com. They have some nice prices on SS Shanks.) FWIW: I'm going to grind and polish my 3 shanks to a smooth finish and keep them as back-ups, or for another project. Moral of the story...you can do it. Just take your time.


garzlok

Well-Known Member
Joined
Aug 19, 2012
Messages
360
Reaction score
221
Location
Dacula
I used a Dremel Metal cut-off wheel. My mistake is I tried to cut off the barb flush with the back of the shank. (I succeeded with two of them.) In hindsight, I should have cut 2-4mm away from the back of the shank and ground down the last 2-4mm of shank material away.


day_trippr

"Now brewing exclusively with Hydrohydroxic Acid"
Joined
May 31, 2011
Messages
34,533
Reaction score
16,069
Location
Stow, MA
fwiw, I was too cheap 13 months ago to replace my shanks with full stainless barbless, so I whacked the barbs off my old chromed brass shanks with a Dremel fiber cut-off wheel...







Cheers!


Gozie Boy

Well-Known Member
Joined
Dec 28, 2017
Messages
216
Reaction score
161
fwiw, I was too cheap 13 months ago to replace my shanks with full stainless barbless, so I whacked the barbs off my old chromed brass shanks with a Dremel fiber cut-off wheel...

View attachment 714230

View attachment 714231

View attachment 714232

Cheers!
Good to know, thanks. I'm facing this exact same issue on my second keezer. We'll see how these wheels deal with SS. Did you then have to also ground down the remaining "nub", or could you cut it close enough to mitigate that need?


day_trippr

"Now brewing exclusively with Hydrohydroxic Acid"
Joined
May 31, 2011
Messages
34,533
Reaction score
16,069
Location
Stow, MA
I rode the flat at the back of the shank with the fiber wheel and what you see is what was left.
I did clean them up, especially chamfering the holes, but that was quite light work...

Cheers!


pvpeacock

Well-Known Member
Joined
Mar 20, 2013
Messages
1,546
Reaction score
857
Location
Palos Verdes Estates
I ended up buying 3 new shanks without a barb or tailpiece. (Checkout RiteBrew.com. They have some nice prices on SS Shanks.)
When I built my keezer, I made the mistake of buying 5" shanks that stick out too much into the keezer and make it difficult to add and remove kegs. I have been meaning to replace them, but didn't want to spend the money. When I saw the prices at RiteBrew, I bought 4 new 3" shanks. Thanks for the tip!
