Oak Barrels, will they hold pressure?

Homebrew Talk - Beer, Wine, Mead, & Cider Brewing Discussion Forum

Help Support Homebrew Talk:

RedIrocZ-28

Well-Known Member
Lifetime Supporter
Joined
Oct 22, 2008
Messages
850
Reaction score
31
Location
Grand Rapids, MI
I have been wanting to get an oak barrel for aging purposes and I have also had this little dream of walking over to the fridge and undoing the spout and pouring a nice beer out of an oak cask after a hard days work. But I have never seen anyone talk about these casks holding pressure, so I don't know how much if any carbonation they could withstand. From a standpoint of their construction I know the sidewalls could handle an immense amount of pressure, but the end caps I am not so sure how they are secured.

Has anyone ever used one of these for serving carbonated beer?

http://cgi.ebay.com/10L-Oak-Wood-Wo...0|66:2|65:12|39:1|240:1318|301:1|293:1|294:50


ClaudiusB

Well-Known Member
Joined
Dec 30, 2007
Messages
1,560
Reaction score
625
Location
El Paso
But I have never seen anyone talk about these casks holding pressure, so I don't know how much if any carbonation they could withstand. From a standpoint of their construction I know the sidewalls could handle an immense amount of pressure, but the end caps I am not so sure how they are secured.
I don't think the barrel in your link can hold much pressure.
Look at my barrel, made for dispensing carbonated German beers.
The walls and caps use 1-1/4" wood.
Compare the walls to my Wine/ Whiskey barrel, 1/2" wood.
My bier barrel has a coating inside to prevent wood flavors.

German Beer Barrel


Wine or Whiskey barrel


Old traditional way of coating a barrel


Cheers,
ClaudiusB


david_42

Well-Known Member
Joined
Oct 8, 2005
Messages
25,581
Reaction score
189
Location
Oak Grove
Wood casks are only used for low-carbonation ales (which is to say CO2 @ only 1 atm). Nothing wrong with that, the whole cult of real ales is based on flat beer.:p

If you are just looking for "cool", get a Party Pig and build a cask around it.


truckmann

Mann Cave Brewer
Lifetime Supporter
Joined
Aug 13, 2007
Messages
483
Reaction score
11
Location
Mannford, OK
They char the inside. Not sure what they are using in that picture. I have heard that they actually build a small fire in the larger barrels as they build them to fully char the inside.


ClaudiusB

Well-Known Member
Joined
Dec 30, 2007
Messages
1,560
Reaction score
625
Location
El Paso
What are they coating those barrels with
Natural tree resin
The new method uses a machine sprayer and rolling machine to coat the inside.

Doesn't look like anything I would want to drink from.
It's safe and all barrels are sanitized.

They char the inside. Not sure what they are using in that picture. I have heard that they actually build a small fire in the larger barrels as they build them to fully char the inside.
Barrel toasting applies to wine & whiskey barrels not German beer barrels.

Cheers,
ClaudiusB


Gordie

Well-Known Member
Joined
Feb 21, 2008
Messages
381
Reaction score
33
Location
Healdsburg, CA
In days of yore, beer barrels were internally coated with resin or pitch to prevent imparting oak flavor or tannin for things like transportation by boat from Burton-on-Trent to India.

Wine and Whiskey barrels are toasted to caramelize the sugars in the oak and encourage oak contribution. Toasting barrels has become quite the science in the past 5 years, but its nothing you'd want in a beer.


TommyBoy

Well-Known Member
Joined
Jul 31, 2008
Messages
525
Reaction score
5
Location
Greenville
I have seen barrels being hand built and charred a while back on TV. I think it was Discovery channel or something. Very cool to watch.


Matt Up North

Well-Known Member
Joined
Jul 4, 2008
Messages
2,023
Reaction score
13
Location
Santa Rosa, CA
They don't much hold pressure, the bungs will pop and if enough is applied then the barrel will explode. I work at a winery and we have a steam machine to clean. We were warned to make sure not to turn the pressure up too high otherwise we will explode a barrel and send shrapnel everywhere. Granted I am talking a whole lot of pressure. If you are going to do it then you are going to want to pressurize low as said above and make sure to drive a wooden bung into the bunghole (a bitch to get out though).

OP
RedIrocZ-28

RedIrocZ-28

Well-Known Member
Lifetime Supporter
Joined
Oct 22, 2008
Messages
850
Reaction score
31
Location
Grand Rapids, MI
I am still looking at getting one of these barrels, maybe not so much now for serving purposes but more for oaking a batch of Stoudt.

I just can't pull the trigger. Its going to cost me $150 for a 5gal barrel delivered no matter what place I order one. Or $225 for a 13gal barrel. Decisions decisions... :(


ClaudiusB

Well-Known Member
Joined
Dec 30, 2007
Messages
1,560
Reaction score
625
Location
El Paso
More info about beer barrels.

Beer barrels don't use wooden bungs like wine & whiskey barrels.
Imaging storing a Weizenbier inside a wine barrel.
The barrels are equipped with special inserts which can be removed for cleaning and maintenance, requires a special tool.
Each insert has a check valve.

Bottom insert removed



Barrels can be connected to standard or old fashion faucets.
I do it the old way with my special tools.



New style plastic stainless beer barrels with old and new way of dispensing beer.


Cheers,
ClaudiusB


OP
RedIrocZ-28

RedIrocZ-28

Well-Known Member
Lifetime Supporter
Joined
Oct 22, 2008
Messages
850
Reaction score
31
Location
Grand Rapids, MI
Claudius, where do you get one of these beer barrels? I have been ninja googling high and low and I am only able to find Wine or Bourbon/Whiskey barrels. I can only assume that these barrels are quite costly, but I have yet to find them.
