I have a 3-inch dial face thermometer gauge that I ordered for my 5-gallon orange rubber made water cooler from homebrew hardware. it did not come with the bolt or washer. I am just going to the hardware store by me. Any idea of what kind of washer I need? do I need 2 washers for the front and back?


Deadalus

Supporting Member
HBT Supporter
Joined
Jan 3, 2020
Messages
619
Reaction score
606
Buy two washers just in case. Then two more of different sizes. I never have enough washers in my house. They're real cheap though.

I am not sure about a cooler but on my keggle I have a washer on the outside and a hex nut and an oring on the inside. I think the oring would be helpful.

OP
alex510

alex510

Well-Known Member
Joined
Aug 19, 2020
Messages
72
Reaction score
7
I am going to inlay the 3-inch face thermometer.


Deadalus

Supporting Member
HBT Supporter
Joined
Jan 3, 2020
Messages
619
Reaction score
606
Inlay meaning it's going through the side wall somewhere? Did you mean a rubber washer initially? I was thinking SS.

Threads are often 1/2" NPT but I think I had a smaller one that was 1/4" NPT? Do have a manufacturer or model number for the thermometer?

OP
alex510

alex510

Well-Known Member
Joined
Aug 19, 2020
Messages
72
Reaction score
7
hi dead yes, I will be going thru the sidewall of the orange round cooler. I think its 1/2 inch.


Deadalus

Supporting Member
HBT Supporter
Joined
Jan 3, 2020
Messages
619
Reaction score
606
So if the threads are a 1/2" NPT, I measured some fittings around the threads with a digital caliper and got about 0.81-0.83". A 7/8" hole would accept those, I think that's the usual suggestion. Hex nuts for 1/2" NPT sometimes have an o-ring channel and that's why I mentioned the o-ring. But a flat (not necessarily thin) rubber washer works too, I have some fittings with those too. The inner diameter there would need to be about 7/8" and the outer bigger than your drilled hole. As far as a metal washer, I find sometimes on the outside these help to stabilize the fitting. I have three vessels, all keggles, with multiple ports and sometimes different types of washers (rubber and SS) and o-rings. You might have some flexibility in the walls of the cooler that affects things. Perhaps a wider (Outer diameter -inner diameter) washer helps there to spread out the force. Thinner (like paper) will conform more to the curvature of the cooler.

But having an extra washer is always a good idea in case you drop it, put it down where you can't find it, need it later. I bought a box of o-rings either off Amazon or from harbor freight which has a bunch of different o-rings. Those are numbered though.

OP
alex510

alex510

Well-Known Member
Joined
Aug 19, 2020
Messages
72
Reaction score
7
hey, dead thank you! I just ordered. I know I need a hole saw bit to cut the orange part. My question is what size drill bit should I use for the hole on the white wall of the cooler?


Deadalus

Supporting Member
HBT Supporter
Joined
Jan 3, 2020
Messages
619
Reaction score
606
13/16" =0.8125" and you could probably screw it in with that since it's plastic but you'd be fine with 7/8". Caveat is if you used a hole saw at 13/16" and it didn't work, you'd have trouble with the next size hole saw as the guide bit wouldn't have anything to grab. At that size hole, regular drill bits are available too if you need them. Hole saw is probably cleaner though. Go slow and keep it square so it doesn't skip with the hole saw.

I used a step bit on all my keggles. I used a hole saw on my jockey box but shanks are a little little larger.


day_trippr

"Feeling much better now, thanks"
Joined
May 31, 2011
Messages
33,909
Reaction score
15,164
Location
Stow, MA
I installed a ton of 1/2" NPT through-wall fittings on my three kettles and nearly every hole was 13/16". 7/8" would be sloppy imo, and especially through a plastic vessel might be important to avoid...

Cheers!


Deadalus

Supporting Member
HBT Supporter
Joined
Jan 3, 2020
Messages
619
Reaction score
606
I installed a ton of 1/2" NPT through-wall fittings on my three kettles and nearly every hole was 13/16". 7/8" would be sloppy imo, and especially through a plastic vessel might be important to avoid...

Cheers!
That's just you on the sloppy call. The outside diameter of 1/2" npt is 0.840", while 13/16" is 0.8125". Sure it's not going to be an exact hole but technically 13/16" is too small (almost 1/32"). 7/8" is 0.875" which is ever so slightly over 1/32". Being made of plastic it wouldn't be difficult to expand the hole if needed. I have many a time though tried to make holes just perfect and spent inordinate amounts of time pulling wires through conduit or conduit and pipes through walls.

You've got choices, happy brewing!

OP
alex510

alex510

Well-Known Member
Joined
Aug 19, 2020
Messages
72
Reaction score
7
hello to all happy wed
The parts came in .I have a question tho. where on the keg\water cooler should I place the gauge? thanks in advance


Attachments

day_trippr

"Feeling much better now, thanks"
Joined
May 31, 2011
Messages
33,909
Reaction score
15,164
Location
Stow, MA
Frankly, I've been wondering about that since the first post :) I have the 10 gallon brother to that cooler, and it has all the same ribbing.

So for sure any through-fitting is totally going to depend on the liner seal, so maybe pick a height that'd land in the middle of your typical mash, but drill between the pair of "ribs" so hopefully whatever goes on the outside will at least sit flat-ish...

Cheers!

OP
alex510

alex510

Well-Known Member
Joined
Aug 19, 2020
Messages
72
Reaction score
7
Hi all
I installed the gauge but it leaks. Any ideas to stop the leak?


day_trippr

"Feeling much better now, thanks"
Joined
May 31, 2011
Messages
33,909
Reaction score
15,164
Location
Stow, MA
Take some close-up pics and post them. We have no idea what you used as a bulkhead and how it's supposed to work...

Cheers!
