My father and I are just adventuring into all-grain using the BIAB method.
I have an old 30L (8gal) ice cooler that I was planning to repurpose as a mash tun. I’ve been experimenting with just water to see how well it holds the heat, but it drops 4.9 degrees Celsius (~8.8 F) over 1 hour with 22L of water @ 65°C/149°F. Ambient temperature was 22°C/72°F.
That sounds like a weak performance, but I am not sure. How much should I expect the temperature to drop in a cheap ice cooler?

Right now we are working on insulating the cooler with styrofoam sheets, but it I think it kind of defeats the purpose of using an ice cooler in the first place.


3 Dawg Night

Life is too short to drink crappy beer.
Lifetime Supporter HBT Supporter
Joined
Apr 14, 2020
Messages
1,169
Reaction score
1,100
Location
Huntsville, AL
That is a pretty big drop. Mine only drops 1-3F over 60 minutes. There's a couple of things you could do:

1) Get a new cooler (they're not that expensive).
2) Wrap a blanket or sleeping bag around it during the mash.

Honestly, I'd give #2 a try first (do your same water test) and see how much of a difference it makes.

There's a big difference in mashing at 140F vs 149F or 158F vs 149F. Those temperatures will make three different beers (but it will still be beer).

OP
Nava854

Nava854

Member
Joined
Mar 1, 2021
Messages
11
Reaction score
7
Location
Spain
Truth be told, this cooler is cheap and veeery old and I’m inclined to believe that it would be worth buying a new one. But my father argues that a new one will perform exactly the same while I believe that it won’t.

And yes, I'm painfully aware of the temperature ranges at which conversion takes place. That is why we are worried by the poor performance. :(


brew_darrymore

Well-Known Member
Joined
Jun 10, 2014
Messages
345
Reaction score
75
Location
Toronto
You can't test the temperature drop just by using water. As @bracconiere said, the thermal mass matters, so once you add the grains, it's likely you'll lose a degree or two at the most. I cover my mash tun with a blanket or sleeping bag for extra insulation.

My mashes usually lose 1-2°F over 60 minutes.


RM-MN

Supporting Member
HBT Supporter
Joined
Nov 26, 2010
Messages
14,516
Reaction score
5,274
Location
Solway
Truth be told, this cooler is cheap and veeery old and I’m inclined to believe that it would be worth buying a new one. But my father argues that a new one will perform exactly the same while I believe that it won’t.

And yes, I'm painfully aware of the temperature ranges at which conversion takes place. That is why we are worried by the poor performance. :(
I have good evidence that your father is wrong. Go look at a 5 day cooler. They will keep ice from melting for 5 days. Try that with the old cooler. Coolers are not that expensive.

Now for the other side of the equation. You lose nearly 5 degrees C during the mash period. How much do you lose while the starch to sugar conversion is going on. Hint: The time for conversion may not be even close to the mash period. It could range from less than 10 minutes to over 2 hours.


madscientist451

Well-Known Member
Joined
May 10, 2014
Messages
4,696
Reaction score
2,309
Location
Bedford
Did you pre-heat the cooler/mash tun with hot tap water?
How many gallons of water were in your test?
The more hot water you put in there, the more thermal mass you have, the longer it will hold a steady temperature.
Put a piece of aluminum foil on top of the mash and then use an old sleeping bag for extra insulation.
I used to BIAB in a cooler, but now I just use the pot on the stove. My electric stove has the smooth glass top that holds some heat, I wrap up the pot in an old coat and keep a pretty steady temperature for an hour.


Jim R

Well-Known Member
Joined
Feb 21, 2020
Messages
266
Reaction score
211
Location
Wisconsin
I heat up 3-4 gallons of water to 170-180 degrees to preheat my cooler for 15 min or so before the mash which slows down cooling considerably. I also keep some hot water on hand and add it if the temperature drops too much after 30 min or so. Since the majority of the mash takes place within the first 30 min, it probably doesn't matter if it drops a little more over 60 min.

On the other hand, a 5 or 10 gal cooler doesn't cost very much.


belgabrewing

Member
Joined
Sep 1, 2013
Messages
14
Reaction score
6
Location
Helotes
I bought a used 10 gallon (5 gallon may be too small for "bigger" beers) Rubbermaid water cooler on Craigslist/ OfferUp. It drops 1-2 degrees over an hour. I picked the Rubbermaid over Igloo because the hole for the spigot is designed so a 1/2 inch stainless close thread nipple fits better with the stainless lock nuts to make a waterproof connection. Rubbermaid also works better because of the threaded lid instead of a friction fit on Igloo which can pop up.


Dancy

Well-Known Member
Joined
Feb 10, 2018
Messages
179
Reaction score
93
Using a 10G Igloo cooler, 10-12lbs of grain, in my kitchen and mashing 154 degrees — lose 2 degrees. I put Reflectix on the lid, figuring heat rises.


3 Dawg Night

Life is too short to drink crappy beer.
Lifetime Supporter HBT Supporter
Joined
Apr 14, 2020
Messages
1,169
Reaction score
1,100
Location
Huntsville, AL
Using a 10G Igloo cooler, 10-12lbs of grain, in my kitchen and mashing 154 degrees — lose 2 degrees. I put Reflectix on the lid, figuring heat rises.
I've also heard that some folks drill a couple of holes in the top of their lid and fill it with expanding spray foam insulation. I have a can of it in my shop, but I haven't tried it yet. I do think that's where the majority of my heat loss is occurring.


Mark3885

Supporting Member
HBT Supporter
Joined
Jun 2, 2015
Messages
91
Reaction score
41
Location
Cattaraugus
The round igloo type water coolers have a hollow lid. I drilled holes in the underside of the lid and injected small crack filling foam . Don’t add too much ( drill multiple holes) the foam will expand the lid .
With preheating the cooler mash tun with mash water 5 degrees above the calculated temperature, I will add all the mash water then add grain and stir until the temperature drops to the mash temp


CascadesBrewer

Supporting Member
HBT Supporter
Joined
Mar 24, 2013
Messages
1,220
Reaction score
780
Location
VA, USA
My father and I are just adventuring into all-grain using the BIAB method.
I have an old 30L (8gal) ice cooler that I was planning to repurpose as a mash tun.
If we back up a little... I am not opposed to mashing in a cooler or repurposing items for whatever type of brewing. One of the appeals of BIAB is doing full volume mashing in the same vessel as using for boiling. An 8 gallon cooler is not going to be big enough for a full volume mash (for a 5 gallon batch). It sounds like your setup leans more toward a 3-vessel setup with a sparge.

How large of a kettle do you have? A 10 gallon kettle is a decent size for full volume mashing for a 5 gallon batch. Then you can skip the cooler.


ajm163

Well-Known Member
Joined
Jan 17, 2012
Messages
252
Reaction score
66
Location
Denver
I've also heard that some folks drill a couple of holes in the top of their lid and fill it with expanding spray foam insulation. I have a can of it in my shop, but I haven't tried it yet. I do think that's where the majority of my heat loss is occurring.
be careful here I tried this (and at least with the foam i used) it was a mess. The mash heated the foam past the melting point and i had a sticky foam mess oozing out of my cooler lid for the whole mash. it was a huge pain


Barbarossa

Beauty is in the eye of the beerholder
HBT Supporter
Joined
Feb 23, 2021
Messages
240
Reaction score
362
Location
Montreal
I would be more worried about the toxicity of the old plastic than losing heat. And I would be worried to lose heat. I didn't dare to use my cheap Coleman cooler because it does not mention that it is food grade.


3 Dawg Night

Life is too short to drink crappy beer.
Lifetime Supporter HBT Supporter
Joined
Apr 14, 2020
Messages
1,169
Reaction score
1,100
Location
Huntsville, AL
I would be more worried about the toxicity of the old plastic than losing heat. And I would be worried to lose heat. I didn't dare to use my cheap Coleman cooler because it does not mention that it is food grade.
Wait, why wouldn't a water cooler be food grade?


Barbarossa

Beauty is in the eye of the beerholder
HBT Supporter
Joined
Feb 23, 2021
Messages
240
Reaction score
362
Location
Montreal
Well I tried to look for the info and found nothing. They don't mention it being food grade. All I found was this:

Non-toxic When Used as Intended:Yes

Hot/Cold:Cold

I assumed that using it for hot liquid was not using it as intended and maybe unsafe. That's all I got. I didn't dare.

OP
Nava854

Nava854

Member
Joined
Mar 1, 2021
Messages
11
Reaction score
7
Location
Spain
I just checked the thread today, and all I can say is thank you so much for all the amazing answers.
A couple of things I want to comment before I leave this for good.

I used a sous vide and cling film to heat up the water inside the cooler (because laziness) and it took more than 30 mins, so my guess is that the temperature of the cooler was already close to mash temp.

I used 22 liters (5.8 gal) for the experiment to simulate the 15 liter (4 gal) batch we're making by adding the same weight of water as malt. Because the specific heat capacity of water is very high, it is very likely that it's also higher than that of malt. That means that the thermal mass of a real mash will be lower, and I believe the loss will be greater... unless the convection was impeded by the floating grain? Actually that would be an interesting experiment to make.

Right now we are interested in doing the mash in a cooler because our heat source is too powerful for mashing in the pot. But in the future we might upgrade our kettle to simplify stuff and do everything in the same place.

And no idea about the toxicity of the plastic. That could be a concern.

Anyway, for this batch we will be using free styrofoam sheets that my friend gave me to insulate the cooler even more and call it a day. And for the next one I'll be buying a new cooler and throw the old one while my dad isn't around. (wink)
