Let me start by saying I just realized I drew my pushbuttons as contacts. If you ignore that, how does this look?
Control circuit for a grain mill
PB1 is on
PB2 is off
PB3 is motor stop
PB4 is motor forward
PB5 is motor reverse
Pushbuttons are all lighted Allen Bradley. I drew in ladder logic because thats what I'm used to. Motor contractors are mechanically interlocked to prevent having both sides energized simultaneously, should I draw in the electrical interlocks as well?
