cask beer ( sort of )

Homebrew Talk - Beer, Wine, Mead, & Cider Brewing Discussion Forum

Help Support Homebrew Talk - Beer, Wine, Mead, & Cider Brewing Discussion Forum:

14th_vermont

Member
Joined
Apr 20, 2022
Messages
9
Reaction score
4
So I brewed a ESB recipe for use in a corny keg. I have it hooked up to a hand pump, from pint365.com, to replicate british style cask beers. While using the hand pump it gets a lot of foam. I have the the co2 psi at 5. I bled off the co2 head pressure in corny keg but it still dispensing quite a lot of foam. Any thoughts or assistance would be great. Love British beer especially cask beer so I set this up in my basement home bar. Thanks


Attachments

  • 20220419_195106.mp4
    13 MB

DuncB

Well-Known Member
Joined
Jun 5, 2019
Messages
2,407
Reaction score
1,393
Location
Paremata New Zealand
Can't beat a beer engine.
Firstly try pulling a bit slower and without the sparkler.
Cellar temp 12 celsius beer and 5 psi is over 1.4 vols, you might want a bit less.
What size tubing internal from keg to check valve? It should be 3/8 in and 1/2 inch out to the engine.
Another thing that will help is to pause for a moment when pulled so that the beer cylinder can refill with a bit less cavitation.


DuncB

Well-Known Member
Joined
Jun 5, 2019
Messages
2,407
Reaction score
1,393
Location
Paremata New Zealand
You need a little bit of pressure only to maintain the condition in the beer and the engine should do the rest for you.
If it's really easy to pull that also hints at the keg pressure being a little too high. Real cask beer would be at atmospheric above the beer and then the engine " sucks " the beer to the glass. Not practical as your beer will oxidise if you open your keg to the air. However a 4l mini keg filled from your corny and then vented will last a few days ( depending on how quickly you drink ) open to the air. But you can top the mini keg up at the end of a session with CO2 and vent and fridge it overnight if you want. I don't bother and don't find that the beer in the engine stales if you have a good pre and finish session cleaning regime.
What regime do they suggest to maintain the lines and engine?
Not an ESB but a Five points bitter clone with fresh hops in whirlpool.
IMG_20220417_152435.jpg IMG_20220417_153338.jpg IMG_20220417_153413.jpg


McMullan

wort maker
HBT Supporter
Joined
Dec 22, 2015
Messages
1,661
Reaction score
2,037
In addition, the serving vessel, cask, keg, or whatever, needs to be 'open'. If CO2 is attached, it needs to be at very low pressure, just enough to replace volume pulled out by the pump. A cask breather or LPG regulator. It's a good idea to have a demand valve in the beer line, to stop beer dripping from the spout or flowing back into the serving vessel. I've been testing 3/8" EVA barrier line recently. It works like a charm.


Edit: What @doug293cz recommends just above (post #7) is very important. Cask ale needs to be conditioned a second time a day or so before serving, where excess pressure/CO2 is released slowly by tapping then venting the cask or keg.

Last edited:

DuncB

Well-Known Member
Joined
Jun 5, 2019
Messages
2,407
Reaction score
1,393
Location
Paremata New Zealand
@McMullan
Nice setup there, I found out the soft spiles are made of Cane. But will be getting some from RLBS in the summer along with a few other necessities such as a cask breather although I do have some 10 litre mylar bags i could fill with CO2 if using a larger keg. I like the decant to smaller keg method because when you're done you can clean via the mini keg as well.


rmr9

Well-Known Member
Joined
Jun 27, 2012
Messages
263
Reaction score
210
Location
Germantown
@McMullan
Nice setup there, I found out the soft spiles are made of Cane. But will be getting some from RLBS in the summer along with a few other necessities such as a cask breather although I do have some 10 litre mylar bags i could fill with CO2 if using a larger keg. I like the decant to smaller keg method because when you're done you can clean via the mini keg as well.
It had never occurred to me to fill a Mylar bag with CO2 to use with a breather. I usually just keep my CO2 tank hooked up but turned off until I draw a pint at 2-3 PSI then shut the tank off again. This seems like a reasonable method that would prevent me from having to even hook my tank up.

OP
OP
1

14th_vermont

Member
Joined
Apr 20, 2022
Messages
9
Reaction score
4
Can't beat a beer engine.
Firstly try pulling a bit slower and without the sparkler.
Cellar temp 12 celsius beer and 5 psi is over 1.4 vols, you might want a bit less.
What size tubing internal from keg to check valve? It should be 3/8 in and 1/2 inch out to the engine.
Another thing that will help is to pause for a moment when pulled so that the beer cylinder can refill with a bit less cavitation.
Not sure on tubing size , whatever came with it from pint 365. I will try some of your suggestions Thank you

OP
OP
1

14th_vermont

Member
Joined
Apr 20, 2022
Messages
9
Reaction score
4
Warm it up to about 50°F, and drop the pressure to 1 psi. That will lower the carbonation from 1.7 volumes to 1.2 volumes, which should help.
ok will do. Does the existing psi have to be bled out ? Or can I just lower it to 1 psi and let it settle and then try again? Thank you


doug293cz

BIABer, Beer Math Nerd, ePanel Designer, Pilot
Staff member
Mod
HBT Supporter
Joined
May 14, 2014
Messages
13,259
Reaction score
10,051
Location
Renton
ok will do. Does the existing psi have to be bled out ? Or can I just lower it to 1 psi and let it settle and then try again? Thank you
Probably best to vent the excess pressure. Otherwise, it will take some time for things to come back into equilibrium. Might need to vent a couple of times a day, for a few days, as excess CO2 comes out of the beer, and builds up pressure in the headspace again.

Brew on :mug:


DuncB

Well-Known Member
Joined
Jun 5, 2019
Messages
2,407
Reaction score
1,393
Location
Paremata New Zealand
You could be cute and fill a sanitised keg or two with the vented gas and then " return " that to offset the beer losses, if you have a spunding valve you can use that to control the gas venting rather than burst venting as suggested by @doug293cz.
Will await an updated video.

OP
OP
1

14th_vermont

Member
Joined
Apr 20, 2022
Messages
9
Reaction score
4
Probably best to vent the excess pressure. Otherwise, it will take some time for things to come back into equilibrium. Might need to vent a couple of times a day, for a few days, as excess CO2 comes out of the beer, and builds up pressure in the headspace again.

Brew on :mug:
So i think the reason for excessive foam is due to fact we raised the psi to 30 for 2 days and rolled corny keg around for a few minutes to speed up carbonation time . This was advised from home brew shop but they were not aware we were using a hand pump to dispense the beer. Beer pours ok from my regular tap but not from hand pump so I think that is problem. So will make corrections after next brew. Thanks all


doug293cz

BIABer, Beer Math Nerd, ePanel Designer, Pilot
Staff member
Mod
HBT Supporter
Joined
May 14, 2014
Messages
13,259
Reaction score
10,051
Location
Renton
You could be cute and fill a sanitised keg or two with the vented gas and then " return " that to offset the beer losses, if you have a spunding valve you can use that to control the gas venting rather than burst venting as suggested by @doug293cz.
Will await an updated video.
If you can find a spunding valve that works at 1 psi (or less) this is a good idea.

Brew on :mug:

OP
OP
1

14th_vermont

Member
Joined
Apr 20, 2022
Messages
9
Reaction score
4
Just keep pouring (and drinking of course) from regular tap with no CO2 connection and you'll soon get the beer
" flat " for the beer engine.
Shut off co2 and will keep pouring and drinking, 3 pints today so far!!!! I will bleed off head pressure from corny keg as well and hook up to hand pump in a day or two. thanks


DuncB

Well-Known Member
Joined
Jun 5, 2019
Messages
2,407
Reaction score
1,393
Location
Paremata New Zealand
@schmurf
The one way ball locks for gas are about the same pressure as well. However they don't let gas out as I found out when I connected my spunding valve to one. Pressure was 35 psi and venting through prv when I returned on day 4. That was tricky to vent the excess gas!!!
