Ball lock quick disconnect

HomeBrewTalk.com - Beer, Wine, Mead, & Cider Brewing Discussion Community.

Help Support Homebrew Talk:

bjhbrew

Well-Known Member
Joined
Oct 15, 2016
Messages
90
Reaction score
32
Based on the wording of the op I’m going to assume you are new to kegging, if not I apologize. Are you aware that you need to pull back on the spring loaded rim at the bottom of the quick disconnect. Doing so allows it to slide on and then releasing it allows it to snap in place. If you’ve ever attached an airline to a pneumatic tool it’s the same.


lump42

The Lajestic Vantrashell of Lob
Joined
Jun 12, 2014
Messages
1,079
Reaction score
643
Location
Bluegrass Region
Yes it is supposed to lock onto the post. There are three balls on the inside of the disconnect that fit into the groove of the post an lock it in place.

1. Pull the disconnect collar up
2. Place disconnect on correct collar
3. with moderate pressure pushing down on the disconnect, release the collar
4. continue pushing on the disconnect until there is a click and the collar returns to its original position


JaymzMF

Well-Known Member
Joined
Apr 26, 2019
Messages
134
Reaction score
313
Location
Reno
I sometimes have trouble on one of my ball locks. Pull back on the collar, push pretty hard while releasing the collar. If not locked, try pulling the whole thing up as if you are taking it off but not pulling up on the collar. This is when mine clicks into place. It's like I've pushed past the locking point and then need to come back a bit to find it. Hope this makes sense and hope it helps.

OP
sictransit701

sictransit701

Well-Known Member
Joined
Jan 29, 2014
Messages
166
Reaction score
18
I’ve done all those things.

1. Pull up collar
2. Push quick disconnect on post
3. Release collar
4. Pull up
But it doesn’t click in place. The whole thing just comes off.


day_trippr

Covid-19 Vaccine Effectivity Test Subject
Joined
May 31, 2011
Messages
35,667
Reaction score
17,954
Location
Stow, MA
Depressurize the keg and use something pointy to press down on the Out post poppet and make sure it moves easily. A wedged poppet won't allow the QD to fully engage...

Cheers!


lump42

The Lajestic Vantrashell of Lob
Joined
Jun 12, 2014
Messages
1,079
Reaction score
643
Location
Bluegrass Region
Depressurize the keg and use something pointy to press down on the Out post poppet and make sure it moves easily. A wedged poppet won't allow the QD to fully engage...

Cheers!
Along the same lines, take the QD apart and make sure it's clean and moves freely as well.


3toes

Well-Known Member
Joined
Jun 5, 2015
Messages
164
Reaction score
62
Location
Denver
I’ve done all those things.

1. Pull up collar
2. Push quick disconnect on post
3. Release collar
4. Pull up
But it doesn’t click in place. The whole thing just comes off.
It's not an AMCYL keg by chance is it? I have trouble with my ball locks seating properly on that keg. I have to push back down on the collar to get it to seat.


shoreman

Well-Known Member
Joined
Feb 1, 2012
Messages
1,201
Reaction score
221
Is it a torpedo keg? I had some issues like that with the posts and morebeer sent out some new ones. Its an issues with those kegs.


doogie

Well-Known Member
Joined
Oct 20, 2016
Messages
211
Reaction score
141
Make sure you are using the proper quick disconnect on the proper post also as the gas and liquid post are different.
If you recently took everything apart and cleaned it, did you keep the In and Out posts in their correct position. They are different.


Franktalk

Well-Known Member
Joined
Jan 19, 2019
Messages
273
Reaction score
175
It's not an AMCYL keg by chance is it? I have trouble with my ball locks seating properly on that keg. I have to push back down on the collar to get it to seat.
I have this too. When I push the QD onto the post, I have to push down on the collar to lock it onto the post.


jungdahl

Active Member
Joined
Dec 22, 2020
Messages
39
Reaction score
3
It's not an AMCYL keg by chance is it? I have trouble with my ball locks seating properly on that keg. I have to push back down on the collar to get it to seat.
I have the same problem on my AMCYL. Just on the liquid side. This is the fourth time I've heard of this issue with the AMCYL. I'm having foam issues although Ive done my due diligence in reaserch on tubing length temp/pressure. I also find the liquid post bottoms out (like metal to metal) when trying to tighten. It's impossible to give that last little snug. I don't have that problem on the gas post.
