So i'm planning on buying a chugger soon and was wondering if I could avoid buying camlocks and use hose barbs everywhere instead. Is that possible ? I use 1/2" ball valves on my setup...


day_trippr

Covid-19 Vaccine Effectivity Test Subject
Joined
May 31, 2011
Messages
35,865
Reaction score
18,289
Location
Stow, MA
You could certainly go sans disconnects, but I wager you'd be pissed you did in fairly short order...

Cheers!


Jon73

Well-Known Member
Joined
Feb 7, 2010
Messages
258
Reaction score
40
Location
Oregon
I went with hose barbs and used 1/2" silicone tubing (good from -100 to 500F). When I'm done I just pull all the lines and put them in a bucket filled with PBW, let em soak for a couple minutes, rinse, drop in a bucket of StarSan then put them away for the next time.

OP
M

matc

Well-Known Member
Joined
May 25, 2005
Messages
275
Reaction score
16
Day tripper, care to let me know why ? I've done a lot of research on camlocks, especially concerning the use of type c camlock restricting the flow. The thing is i don't see why I should spend 60$ on camlocks if they're not necessary. It's not like i'm gonna work 8hours a day on my brew rig so i don't mind yanking on hoses


Bobby_M

Vendor and Brewer
HBT Sponsor
Joined
Aug 3, 2006
Messages
25,221
Reaction score
4,179
Location
Whitehouse Station
There's no problem using hose barbs, it's just not as convenient. I have 5/8" hose barbs with female thread for the input of the pump, then use a 5/8" barb with male threads on the output after the ball valve.

OP
M

matc

Well-Known Member
Joined
May 25, 2005
Messages
275
Reaction score
16
All right thanks bobby ! I'll place an order soon !


NathPowe

Well-Known Member
Joined
Nov 28, 2012
Messages
601
Reaction score
146
I just added a chugger to my setup (also via BobbyM - great vendor). I'll agree with daytripper and BobbyM in that, while the camlocks certainly aren't necessary, they certainly are convenient. I only do a few hose changes per brew on my system, but having the camlocks sure does make thing easier. It was money well-spent it my opinion.

YMMV however, so good luck with whatever you choose. Enjoy the brew.


Bobby_M

Vendor and Brewer
HBT Sponsor
Joined
Aug 3, 2006
Messages
25,221
Reaction score
4,179
Location
Whitehouse Station
A partial compromise is to use barbs on the pump side of the hose, which will require many fewer changes and then go camlock on the vessel side.


rgauthier20420

Well-Known Member
Joined
Sep 20, 2012
Messages
771
Reaction score
70
So i'm planning on buying a chugger soon and was wondering if I could avoid buying camlocks and use hose barbs everywhere instead. Is that possible ? I use 1/2" ball valves on my setup...
I used to go the same route before I upgraded. Using the screw driver to loosen and re tighten the hose clamps each time you need to move a hose is perfectly doable. But, it does get annoying like people have said not to mention your close to the flame or HOT pot. I was able to get my QD's at a great price, but I think it's an investment that will make your brew session easier in the long run. Your upgrading to a pump...why not go a little further and do the connections while your at it. Good luck either way!


Schemy

Well-Known Member
Joined
May 13, 2011
Messages
877
Reaction score
134
Location
Omaha
I just added a chugger to my setup (also via BobbyM - great vendor). I'll agree with daytripper and BobbyM in that, while the camlocks certainly aren't necessary, they certainly are convenient. I only do a few hose changes per brew on my system, but having the camlocks sure does make thing easier. It was money well-spent it my opinion.

YMMV however, so good luck with whatever you choose. Enjoy the brew.
Same here. I just used my new set up yesterday, and kicking myself for not doing it 20 brews ago.


kjackson82

Well-Known Member
Joined
Feb 18, 2013
Messages
69
Reaction score
4
Location
Greenville
Have a battery operated drill and a 1/4" nut driver bit? Makes for quick hose clamp loosening and tightening! If you have the soft silicone tubing just use one of the torque settings instead of the drill setting as to not rip the tubing up by over torquing.


day_trippr

Covid-19 Vaccine Effectivity Test Subject
Joined
May 31, 2011
Messages
35,865
Reaction score
18,289
Location
Stow, MA
Same here. I just used my new set up yesterday, and kicking myself for not doing it 20 brews ago.
And that conclusion is where my comment came from.

It's not just operating swaps, it's cleaning, storage, etc, without chewing up heavy wall silicone tubing - which isn't exactly cheap stuff to replace prematurely...

Cheers!


Jon73

Well-Known Member
Joined
Feb 7, 2010
Messages
258
Reaction score
40
Location
Oregon
FWIW, I have been using the silicone tubing for well over 20 brews and have not replaced any of the lines. The SS hose barbs make a pretty tight fit and you don't have to torque the hose clamps all that much.

OP
M

matc

Well-Known Member
Joined
May 25, 2005
Messages
275
Reaction score
16
ok thanks guys. I think I'll settle on camlocks...Might as well shell a few bucks more and do it properly


Steampunk

Well-Known Member
Joined
Oct 24, 2011
Messages
136
Reaction score
2
Location
Oakville
For what it's worth I pulled the trigger on my second pump. Didn't want to deal with all the connecting and disconnecting so bought a bunch 3 way ball valves then just used barbed fittings on each output.

No connecting or dissconnecting.

Joined
Jan 5, 2012
Messages
4,718
Reaction score
812
Location
Atlanta
Steampunk said:
For what it's worth I pulled the trigger on my second pump. Didn't want to deal with all the connecting and disconnecting so bought a bunch 3 way ball valves then just used barbed fittings on each output. No connecting or dissconnecting.
I use s barbed fitting on my pump inlet and on the connections to my CFC and the whirlpool return on my BK BUT I also secure the silicone hoses w/ large plastic ratcheted clamps. They're easy on and off plus cheap. This way I don't worry about a surprise disconnect.
