What do you use for your heat shields for your propane burners?

Discussion in 'Equipment/Sanitation' started by JUSTINTIMEBREWING, Feb 7, 2010.



  1. #1
    JUSTINTIMEBREWING

    Well-Known Member

    Posted Feb 7, 2010
    Whats good to use or can you just buy these?

  2. #2
    BargainFittings

    Vendor / Owner

    Posted Feb 7, 2010
    deleted

  3. #3
    ColoHox

    Compulsive Hand Washer

    Posted Feb 6, 2013
    Heating galvanized metal makes for a pretty stinky, and hazardous smoke. I guess it would be ok after "cooking" it off.

    I found 6"x24" 16 gauge mild steel at lowes, and ordered the two stainless brackets.

    burner crop.jpg

    Jayhem likes this.
  4. #4
    Jayhem

    Well-Known Member

    Posted Feb 6, 2013
    I use aluminum roofing cut into 24" tall sections. It can be bent to form a half-circle. I use 2-3 of these to surround my burner stand and lower part of my brew pot. It blocks 90% of wind from getting to the flame and in my experience saves at least 30% of my propane as I can leave the burner on 50% and still maintain a rolling boil!

  5. #5
    Islandboy85

    Well-Known Member

    Posted Feb 6, 2013
  6. #6
    processhead

    Supporting Member

    Posted Feb 7, 2013
    I guess I would call mine more of a windshield than a heat shield. Its a cut off section of a 32 gallon steel drum that allows me to brew outdoors during windy days. I don't use it when I brew inside.
    No fancy stainless or galvanized finish on mine, just plain old iron oxide.

    2013-02-06 21.37.04 (Small).jpg

    Jayhem likes this.
  7. #7
    mjohnson

    Well-Known Member

    Posted Feb 7, 2013
    aluminum foil.

  8. #8
    itzkramer

    Well-Known Member

    Posted Feb 7, 2013
    Sheet metal and rivets.


  9. #9
    worxman02

    Supporting Member

    Posted Feb 8, 2013
    I used aluminum flashing from Home depot and as I had figured, parts of it melted from the heat of the burner. It wasn't too expensive and it was easier to get then stainless. I didn't want to use galvanized since the fumes that come off when it heats up are toxic, and I didn't want mild steel since it would just rust. Even with my slightly melted heatshield it still works much better than nothing at all.
