Old 10-12-2010, 07:21 PM   #891
DeBrewer
Recipes

Aug 2010
The South
Posts: 238
Liked 17 Times on 9 Posts


A sneak peek at my build. Designed a few different approaches in my head and this one triumphed based on my needs. It is a Blichmann-esque principal with a twist. It collapses to a maximum length of no more than 3 feet and fits in the trunk of my TL-S with room to spare. It is lite and can be assembled in a few minutes with a handful of bolts and two wrenches. Burners etc.. should be here Friday. Third keggle not pictured Everything used can be purchased at Lowe's. Full write up to come.... Cheers!!!







Reply With Quote
Old 10-12-2010, 07:39 PM   #892
klyph
Recipes

Dec 2009
North Pole, Alaska
Posts: 1,809
Liked 42 Times on 38 Posts


Will you be securing that top keg some how? It doesn't appear level, and I don't imagine 10 gallons of strike water dumping out on you would be very pleasant.
__________________
10 gallon electric system
Stovetop 110v single vessel 5 gallon system

Primary: saison
Secondary: nada
Conditioning: macaroon stout
Drinking: store bought


Reply With Quote
Old 10-12-2010, 09:20 PM   #893
homebeerbrewer

homebeerbrewer's Avatar
Recipes

Jun 2008
Home, where the beer is, NH
Posts: 2,062
Liked 108 Times on 93 Posts


That could be an optical illusion. The ladder in the background doesn't look level, so it could make the other objects in the picture look unlevel (is that a word?) too.

I'm wondering how strong that center piece is. Will it hold the weight?
__________________
BEER - Brew Enjoy Empty Repeat


Reply With Quote
Old 10-13-2010, 04:23 AM   #894
Hsmithmathews
Recipes

Jul 2008
Atlanta
Posts: 9



This is my sculpture, its a work in process. just finished the automated valves


Reply With Quote
Old 10-13-2010, 04:26 AM   #895
Hsmithmathews
Recipes

Jul 2008
Atlanta
Posts: 9

Here are more images, let me know what you think...





Reply With Quote
Old 10-13-2010, 06:11 AM   #896
klyph
Recipes

Dec 2009
North Pole, Alaska
Posts: 1,809
Liked 42 Times on 38 Posts


Very nice, not the most compact design, but very utilitarian, I bet you'll brew some mighty fine beer on it. I like the control panel.
__________________
10 gallon electric system
Stovetop 110v single vessel 5 gallon system

Primary: saison
Secondary: nada
Conditioning: macaroon stout
Drinking: store bought


Reply With Quote
Old 10-13-2010, 02:02 PM   #897
DeBrewer
Recipes

Aug 2010
The South
Posts: 238
Liked 17 Times on 9 Posts


Quote:
Originally Posted by klyph View Post
Will you be securing that top keg some how? It doesn't appear level, and I don't imagine 10 gallons of strike water dumping out on you would be very pleasant.
Yes it will be secured. I am planning on welding some small uprights on each platform to secure the bottom from sliding and then using straps around the keg to the stand itself. I was in Wal Mart this weekend and found what function like a bunjee(sp) but are thin and wide like a strap. They are adjustable and fit perfectly around the keg and hook into the square tubing.

The stand does sit slightly crooked in the pic but the ladder makes it look way off. The reason it sits crooked is that when I was tacking it all togethar it was flat on the concrete but when I welded the underside of the legs(vertical L channel to the square runners) it threw everything out of whack from the bead line. A little grinding should fix that. I am also planning on putting some form of adjustable leveling pads on the ends of the legs.

Each leg can be unbolted from the square tubing and the square tubing comes apart in three sections and each platform is removable. I need to take a pic of it disassembled. It can easily be assembled, disassembled, and carried by one person. Although it may never be the roaming brew stand, space is a concern in suburbia since my automotive fetish gets the majority of the garage. This will be stored in the "brew room" (spare bed room) next to my kegorator/fermentation chamber. Temp controlled chamber that fits 4 carboys and the kegorator side that still holds 8 cornys. Yet another work in progress.....


Reply With Quote
Old 10-13-2010, 02:35 PM   #898
EarthBound
Recipes

Mar 2010
Beer Capital of the World
Posts: 1,069
Liked 12 Times on 11 Posts


Here's my rig

__________________
"You can do anything you set your mind to when you have vision, determination, and an endless supply of beer."


Reply With Quote
Old 10-14-2010, 10:36 PM   #899
ghart999
Recipes

Dec 2005
Denver
Posts: 511
Liked 7 Times on 6 Posts




Reply With Quote
Old 10-15-2010, 06:21 PM   #900
moxie
Recipes

Feb 2010
Halifax, N.S.
Posts: 145

I just went through this entire thread at work, and I've got to say that it's interesting to see such a diverse range of equipment being incorporated here. I am brewing 5 Gal AG batches, using a plastic fermenter as an HLT, and a 10 gallon cooler as a mash tun... I am a fit guy, but lugging around huge pots of scalding hot water is disheartening indeed. I would love to built one of these brew rigs, but I am just starting to scratch the surface in terms of HERMS, RIMS, and whatever else there is to learn. I would love to get beyond using my refrigerator and a table chair to create a makeshift 3 tier brewery, there is some real inspiration in here, if only I had some skills in welding.

What is the mecanno looking stuff I have seen in here? It looks like it is pre-rigged with holes for simple fabrication. Is this stuff cost effective/reliable? Are there any other examples of this stuff being used for brew rigs?

By the way, that green beast above is a real 'beaut.


Reply With Quote
