Old 10-21-2012, 03:28 PM   #1
hedbutter
Recipes

May 2012
Pittsburgh, PA
Posts: 187
Liked 7 Times on 6 Posts



As I'm waiting for my second brew to finish up, I figured I would start the thread of my kegerator build. I will be using the GE- SMR04DAMWW, a 4.3 cuf minifridge that cooled my beer in college, so its only natural that it now gets turned into a kegerator for my homebrews.

On the Refridgerator:
  • Door Shelf is held on by screws
  • Can fit 2 cornies and a 5lb CO2
  • Cooling lines are on sides, with 1 on top
  • Freezer shelf is easily bent into place

Progress:
So far, i have completed bending down the freezer shelf, which I plan on attaching a small fan to, to help with tower cooling. So far, i have all needed parts but not all of the needed tools (i will be picking them up today after I finish my holliday brew).

More Pictures and steps to follow tonight/tomorrow!
__________________
It's not about finding the best beer, but finding the best in every beer.


Reply With Quote
Old 10-28-2012, 01:37 AM   #2
hedbutter
Recipes

May 2012
Pittsburgh, PA
Posts: 187
Liked 7 Times on 6 Posts


Sorry for such a delay, but the kegerator is finished!

First- Remove inner door shelving and attach replacement plastic. (no Pic)

Next- Bend down the freezer shelf after letting it sit turned off for awhile (also remove thermostat from shelf):


Once the shelf is bent down, take your measurements and double check where you want to add the tower (make sure you account for the base of the tower). Once its measured, drill a pilot hole and then use your whole saw.
Top:

Inside:

Always measure twice and double check your calculations! As you can see, I messed up math the first time and was off by a substantial amount.

The Core:


Next, line up your draft tower, mark the mounting holes, drill them out and attach your tower.


Finally, remove the top piece of plastic, add draft parts and drip tray(i have purchased a larger one, not picture)
__________________
It's not about finding the best beer, but finding the best in every beer.


Reply With Quote
Old 12-27-2012, 09:39 PM   #3
Big_Blue

Big_Blue's Avatar
Recipes

Sep 2012
Camarillo, CA
Posts: 137
Liked 13 Times on 12 Posts


I'm working on this exact same model. How did you end up handling the thermostat? I'm still bending the freezer down and remain absolutely terrified.


Reply With Quote
Old 12-28-2012, 03:05 PM   #4
hedbutter
Recipes

May 2012
Pittsburgh, PA
Posts: 187
Liked 7 Times on 6 Posts


Quote:
Originally Posted by Big_Blue View Post
I'm working on this exact same model. How did you end up handling the thermostat? I'm still bending the freezer down and remain absolutely terrified.
Current, the thermostat is just hanging off of its mounting screw by the wire, towards the back of the fridge. This lets the two cornies fit (although extremely tight) but it is hard to adjust the temp. i'm going to look into a different mounting place, but for not, it works fine. If you have any other questions, feel free to shoot me a PM and i'll give you any helpful information/pictures i can
__________________
It's not about finding the best beer, but finding the best in every beer.


Reply With Quote
Old 01-26-2014, 05:10 AM   #5
spaceyaquarius
Recipes

Mar 2013
Oklahoma City, OK
Posts: 402
Liked 11 Times on 10 Posts


The Danby DCR122BLDD has the same freezer compartment issue. Just unscrew the freezer, and very slowly push it back against the back wall of the fridge.

http://www.homebrewtalk.com/f51/danb...ersion-455781/


Reply With Quote
