Old 01-10-2012, 08:20 PM   #11
Vomtaylor
Recipes

Dec 2011
Temecula, Ca
Posts: 25

Sweet new Rims... Cant wait to get mine up and running.... Thanks for the stand too..


Reply With Quote
Old 01-10-2012, 09:13 PM   #12
Coldies
Recipes

Oct 2010
Carlsbad, CA
Posts: 572
Liked 7 Times on 7 Posts


Tommy, get your burners ordered so we can finish that thing.


Reply With Quote
Old 01-10-2012, 10:29 PM   #13
SmokingDog

SmokingDog's Avatar
Recipes

Feb 2011
Sheboygan, WI
Posts: 126
Liked 2 Times on 2 Posts


OT - true hard-tail with an EVO in the background?


Reply With Quote
Old 01-10-2012, 11:32 PM   #14
Coldies
Recipes

Oct 2010
Carlsbad, CA
Posts: 572
Liked 7 Times on 7 Posts


Quote:
Originally Posted by JonesCreek View Post
OT - true hard-tail with an EVO in the background?
1200 sporty engine. cut the bike in half and welded the hardtail on. New tank, bars, oil tank, pipes, chain conversion, tires, seat, tail light, etc... (Long list). The bars, pipes and all mounting brackets were all made by hand (and homebrew) I spent many nights in the garage on that one.


Reply With Quote
Old 01-11-2012, 12:57 AM   #15
Formito
Recipes

Oct 2011
Wilmington, DE
Posts: 85

Where did u get the RIMS heat exchanger?


Reply With Quote
Old 01-11-2012, 04:26 PM   #16
Coldies
Recipes

Oct 2010
Carlsbad, CA
Posts: 572
Liked 7 Times on 7 Posts


Quote:
Originally Posted by Formito View Post
Where did u get the RIMS heat exchanger?
I got it from another HBT member who lives local to me, mikelikesit2000. I was going to have a friend build me one but it would have taken longer than I wanted.


Reply With Quote
Old 01-23-2012, 03:33 PM   #17
Coldies
Recipes

Oct 2010
Carlsbad, CA
Posts: 572
Liked 7 Times on 7 Posts


Well I finished my stand enough to brew on it twice now. I got use to everything the second time around and def like not having to switch out hoses, lift kettles and manually pour hot liquid or wort. Here are a few photo's of the finished (for now) stand in the middle of a brew session.

I brewed a coconut brown that I toasted a pound and a half of coconut, added 1/2 lb to the mash and the remaining lb with 15 min left.

[IMG][/IMG]

Here is my RIMS tube mounted, I used U-bolts that attach to tabs that I welded on. I have it mounted at a slight angle to aid in draining. The back side of the tabs is also were the ground is threaded onto the U-bolts.

[IMG][/IMG]

A shot while mashing

[IMG][/IMG]

Temps holding steady

[IMG][/IMG]

The coconut was finely shredded so I used a hop bag I had.

[IMG][/IMG]


Reply With Quote
Old 01-23-2012, 03:37 PM   #18
Coldies
Recipes

Oct 2010
Carlsbad, CA
Posts: 572
Liked 7 Times on 7 Posts


Had to take a cider break before I collected my first runnings.

[IMG][/IMG]

First runnings.

[IMG][/IMG]

Camera went dead after that but here is a shot of my fermentor chamber. I used a old fridge I had and cut holes in the bottom and added some black PVC pipe for the air chamber

[IMG][/IMG]
[IMG][/IMG]

One fan blows the cold air down while the other pulls the warmer air up out of the chamber.
[IMG][/IMG]

And here is the coconut brown still fermenting hard.

[IMG][/IMG]


Reply With Quote
Old 01-23-2012, 03:45 PM   #19
Coldies
Recipes

Oct 2010
Carlsbad, CA
Posts: 572
Liked 7 Times on 7 Posts


I really dig the new stand. The next upgrade is to eventually swap out all the brass for Stainless. I already priced it out and its around $100. That will included all my pump fittings and the brass valves on the MLT. It would clearly only be for bling factor since it functions fine for now.
[IMG][/IMG]


Reply With Quote
Old 01-23-2012, 04:29 PM   #20
kickrjason

kickrjason's Avatar
Recipes

Jun 2011
Phoenix, AZ
Posts: 285
Liked 5 Times on 5 Posts


I really like your set up. Your rims tube looks very clean. You have any details on it and or would your friend be willing to make another?

North county beer is definitely where it's at. The Abby and I have a longstanding date every time I go visit my in-laws in Escondido
__________________



Tap#1 Summer Saison
Tap#2 Amarillo Pale Ale

Primary English Mild
Secondary -Vanilla Chai Mead

Kegged Has Hefeweisen #4, Speckled Heifer Cream Ale
Bottled - Cherry Oatmeal Stout, Burbon Vanilla Oatmeal Stout, Blueberry Hefeweisen, Stubborn Baby Pale Ale,


Reply With Quote
