Default Bobby style keggle jig

I really like passedpawn's cutting jig but since my Dewalt angle grinder didn't have a screw mount in the top of the head, I decided to go with a quick mock up of Bobby_M's tried-and-true model. Works pretty well, went through about one and a half 1/16" x 4.5" metal cutting blades in about 15 minutes. Thanks, Bobby.

BEFORE



AFTER




Reason: pics
Maltose is offline

Reply With Quote
Old 08-02-2010, 11:14 PM   #2
wildwest450
Registered User
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2007
Posts: 9,099
Liked 170 Times on 155 Posts
Likes Given: 4

Default

Pic fail.


wildwest450 is offline

Reply With Quote
Old 08-02-2010, 11:19 PM   #3
Maltose
Feedback Score: 0 reviews
Recipes

Join Date: May 2010
Location: Frederick, MD
Posts: 471
Liked 2 Times on 2 Posts
Likes Given: 1

Default

fixed!
Maltose is offline

Reply With Quote
Old 08-03-2010, 02:09 AM   #4
x2wdtoyotax
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2009
Location: Seoul, South Korea
Posts: 68
Default

Nice... I also have a dewalt grinder. I gotta try that!
__________________
My current brews...

MiniBrew 6.5 - Firestone Pale 31 Clone (oaked)
5 Gal Secondary - Empty

Keg 1 - Empty
Keg 2 - Empty

Bottled -
Belgian Summer Saison
x2wdtoyotax is offline

Reply With Quote
Old 08-03-2010, 04:56 PM   #5
MSUConrad
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2008
Location: Raleigh, NC
Posts: 198
Default

You may already done this, but take a grinding wheel and then a flap wheel to the cut. It'll clean up the edges and prevent you from cutting your arm and fingers when using it.
MSUConrad is offline

Reply With Quote
Old 08-03-2010, 07:05 PM   #6
Maltose
Feedback Score: 0 reviews
Recipes

Join Date: May 2010
Location: Frederick, MD
Posts: 471
Liked 2 Times on 2 Posts
Likes Given: 1

Default

yeah i used a medium grit then finished it off by hand with a soft grit sandpaper. it doesn't take much contact to open you up a little--i don't think a photo of this from yesterday is necessary

i've been hearing that about 1" above the bottom weld is the usual place to put a 1/2" coupler for a ball valve. is that correct? obviously you would want it as close to the bottom as you can get it, but just to get an idea. i also have 2 false bottoms from sabco for the BK and MLT, should the ball valve be up higher in order to use a dip tube on these?
Maltose is offline

Reply With Quote
Old 08-03-2010, 08:04 PM   #7
MSUConrad
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2008
Location: Raleigh, NC
Posts: 198
Default

About 1 inch is around the right spot, but the most important thing is too make sure your entire coupling is on a level spot. Meaning you must get it above the bottom curvature near that bottom weld.

Most false bottoms sit pretty low in the keg, so you should not have a problem with the diptube there. But I would certainly wait until you get your false bottom to test fit it. It's really hard to patch a hole in a keg!

And as long as you have a dip tube, and your solder joints are good, it really does not matter how high off the bottom you valve is (within reason).
MSUConrad is offline

Reply With Quote
Old 08-03-2010, 08:19 PM   #8
klyph
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2009
Location: North Pole, Alaska
Posts: 1,809
Liked 39 Times on 35 Posts
Likes Given: 3

Default

I have that same grinder, my design was a tad less bulky, but yours was probably easier to operate.







Sorry for the thread jack, you did a nice job on that keg. Did you cut a specific diameter to accept lids?
__________________
10 gallon electric system
Stovetop 110v single vessel 5 gallon system

Primary: saison
Secondary: nada
Conditioning: macaroon stout
Drinking: store bought
klyph is offline

Reply With Quote
Old 08-03-2010, 08:23 PM   #9
Maltose
Feedback Score: 0 reviews
Recipes

Join Date: May 2010
Location: Frederick, MD
Posts: 471
Liked 2 Times on 2 Posts
Likes Given: 1

Default

yeah, 12". i really like your design. mine cost me about $2 for the bolts. already had a grinder and used some of my landlord's extra baseboard in the basement
