Default My Automated E-Herms Build (LabJack)

So after about 2 months of work I am finally at the point where I feel comfortable showing off my rig! I also have a few videos of my first brew session. I have a long way to go in the programming department to get the automation set up and I am really lazy when it comes to writing code. I stopped after I got it into the BK as everyone on here I think knows what to do after that, and if not there is already tons of info for it.

Any feedback is welcome. Let me know what you think! This was my first time brewing AG as well so please let me know if my technique is screwed up.

PICS!
The Rig.

7" Touchscreen Mounted on Computer case on wall

Boil Kettle

Mash Tun

HTL/HERMS Hex
