Default Side by Side Fridge to Fermenter

After reading through many options for fermentation control I decided that converting a side by side fridge was probably the best way to go. For the past year I have been using an A/C unit with a Johnson control attached to an insulated chamber...not very efficient and running constantly in the summer to maintain 67 degrees.

So I acquired a side by side fridge and freezer for free from my roommate's parents and started ripping it apart. I've only seen this done once on HBT so it was a very experimental project.

I started by removing the center wall that divides the fridge and freezer. This is the dirty work but overall it was easy. Make sure you don't hit any electrical lines or thermostats.

The rest of the work was done by some friends that are experts at special projects and engineering. They measured out all the shelving and we figured out a system that would give us the most capacity. The wood is drilled very securely and even through the fridge's outside walls.

When we pulled out the front door seal (where the 2 doors meet in the middle) we accidentally cut into a freon line. Luckily my friends are also very knowledgeable with fixing this type of thing and were able to braze and flush the line...then they ran it through the rear of the unit so it wouldn't be in the way.

We drilled a hole in the side to mount the johnson control unit and insert the probe. And to seal the front doors we just added window sealing so when you close the doors at the same time it creates a perfectly tight seal.

It works perfectly! We fired it up today and the Johnson control was reading 26 degrees after just a few minutes. This is going to be super efficient at keeping ales in fermentation temps and getting started with lagering!

Check out the pics below and let me know if you have any questions. The capacity is 4 better bottles on the top shelf, 2 on the bottom, plus a 15 gallon demijon. So all in all the capacity is 40 gallons!




__________________
steveo929 is offline

Reply With Quote Quick reply to this message
Old 08-12-2011, 02:33 AM   #2
day_trippr
Feedback Score: 0 reviews
Recipes

Join Date: May 2011
Location: Stow, MA
Posts: 10,608
Liked 1285 Times on 1036 Posts

Default

Wow! That's amazing! Just when you think you've seen pretty much everything when it comes to beer chilling mods, you see something even more radical!

Good job to you and your crew!

Cheers!

__________________
day_trippr is offline

Reply With Quote Quick reply to this message
Old 08-12-2011, 02:48 AM   #3
seabass07
Feedback Score: 0 reviews

seabass07's Avatar
Recipes

Join Date: Apr 2011
Location: Brothell
Posts: 1,246
Liked 120 Times on 91 Posts
Likes Given: 71

Default

Genius!

__________________
seabass07 is offline

Reply With Quote Quick reply to this message
Old 08-12-2011, 11:14 PM   #4
ROLF42
Feedback Score: 0 reviews
Recipes

Join Date: Aug 2011
Location: EDGEWATER, NEW JERSEY
Posts: 2
Default Fermentation cooler

You must have some very smart friends to make this set up work.
Your idea was great. Putting it all together was an act of pure genius.

__________________
ROLF42 is offline

Reply With Quote Quick reply to this message
Old 08-13-2011, 03:12 PM   #5
bhamade
Feedback Score: 0 reviews
Recipes

Join Date: Jul 2010
Location: Georgia
Posts: 115
Liked 2 Times on 2 Posts
Likes Given: 5

Default

I just got a side by side fridge for 30 bucks today. I am going to try this!

__________________
bhamade is offline

Reply With Quote Quick reply to this message
Old 08-13-2011, 08:20 PM   #6
bhamade
Feedback Score: 0 reviews
Recipes

Join Date: Jul 2010
Location: Georgia
Posts: 115
Liked 2 Times on 2 Posts
Likes Given: 5

Default

Okay I have a question. I began messing with the center divider and came upon this:




Is that the freon line?

__________________
bhamade is offline

Reply With Quote Quick reply to this message
Old 08-13-2011, 08:41 PM   #7
gromitdj
Feedback Score: 0 reviews
Recipes

Join Date: Feb 2008
Posts: 146
Liked 7 Times on 5 Posts
Likes Given: 1

Default

Quote:
Originally Posted by bhamade View Post
Okay I have a question. I began messing with the center divider and came upon this:

Is that the freon line?
Looks like it to me. You probably want to leave that center divider in anyhow, as it provides a sealing surface for both of the doors where they meet in the middle. Have a look at Boerderij_Kabouter's side by side to see how he did it.
__________________

Donnie

gromitdj is offline

Reply With Quote Quick reply to this message
Old 08-13-2011, 08:58 PM   #8
ROLF42
Feedback Score: 0 reviews
Recipes

Join Date: Aug 2011
Location: EDGEWATER, NEW JERSEY
Posts: 2
Default Freon line

Yes that is the freon line. If you have a friend or known someone who can evxcuate the freon then you can relocate the line so that it is not in you way.

__________________
ROLF42 is offline

Reply With Quote Quick reply to this message
Old 08-13-2011, 09:33 PM   #9
bhamade
Feedback Score: 0 reviews
Recipes

Join Date: Jul 2010
Location: Georgia
Posts: 115
Liked 2 Times on 2 Posts
Likes Given: 5

Default

Quote:
Originally Posted by ROLF42 View Post
Yes that is the freon line. If you have a friend or known someone who can evxcuate the freon then you can relocate the line so that it is not in you way.
Thanks man. I can make it to where the doors seal. That's the easy part. The moving of the freon line is the hard part.
__________________
bhamade is offline

Reply With Quote Quick reply to this message
Old 08-14-2011, 06:57 AM   #10
steveo929
Feedback Score: 0 reviews
Recipes

Join Date: Jan 2010
Location: New York, NY
Posts: 129
Default

For some frezion reason they have a line running up the front! Don't cut into it. I was lucky that my friends could fix it, otherwise that would be an expensive mistake. Let me know if you have questions, I can ask the experts and get right back to you.
