Old 02-04-2009, 10:21 PM   #11
Bokonon
Feedback Score: 0 reviews
Recipes

Join Date: Mar 2007
Location: Tri-Cities, WA
Posts: 1,297
Liked 9 Times on 9 Posts

Default

Quote:
Originally Posted by yermej View Post
Another option that would be a little more work (and involve a computer) is some sort of X10 protocol based equipment (or other home automation protocol like Insteon). You could easily program the computer for any sort of on/off intervals you wanted. It might cost a bit more than $20, but definitely not the $170 you found in my previous link.

Again, it would require a computer, but that could be anywhere in the house as the home automation gizmos use power line and/or RF communication.
This is exactly what I did at some point before I had a stirplate. I think I might have even posted on the forum here about doing it.

Of course I already had the X10 gear and PC with software on it
__________________
Bokonon is offline

Reply With Quote Quick reply to this message
Old 02-04-2009, 10:56 PM   #12
ScubaSteve
Feedback Score: 0 reviews

ScubaSteve's Avatar
Recipes

Join Date: May 2007
Location: New Bern, NC
Posts: 3,674
Liked 62 Times on 46 Posts
Likes Given: 11

Default

I think the BC460 state machine might work.....

ScubaSteve is offline

Reply With Quote Quick reply to this message
Old 02-04-2009, 11:33 PM   #13
bull8042
I like 'em shaved
Feedback Score: 0 reviews

bull8042's Avatar
Recipes

Join Date: Jul 2008
Location: Fort Mill, SC
Posts: 10,279
Liked 445 Times on 443 Posts
Likes Given: 11

Default

Quote:
Originally Posted by menschmaschine View Post
I can't believe it... you of all people to misspell my name!
HAHAHA! With such a fricken judicious use of consonants, what do you expect? I work for a German company and have to deal with the language every single day. Consonants must be dang cheap over there!
__________________
"I brew with a water cooler and some part from the toilet." - JohnnyO

"I do gravity feed the last gallon or two through my Therminator, but I expect you could suck start a Volkswagen before you could suck start one of these. - GilaMinumBeer

"..... Bull was right." - TXCurtis
bull8042 is offline

Reply With Quote Quick reply to this message
Old 02-04-2009, 11:44 PM   #14
bull8042
I like 'em shaved
Feedback Score: 0 reviews

bull8042's Avatar
Recipes

Join Date: Jul 2008
Location: Fort Mill, SC
Posts: 10,279
Liked 445 Times on 443 Posts
Likes Given: 11

Default

Kai, I don't see why you couldn't do it cheaply with a couple of timing relays. One relay with a delay on and the other with a delay off. Let me see if I can make this explanation as convoluted as possible..... Relay with a "time off delay" (Relay A), one set of NO contacts powering your valve and a set of NC contacts powering the coil of the other relay. The "other" relay is a "time on delay" (Relay B). A set of NO contacts power the first relay coil.
Adjust "Relay B" to 5 minutes, when the time is up it will close the contacts, thereby powering the coil of "Relay A" and start it's timing cycle. Once relay A (set to 1 min) completes it's cycle, it will switch and close the...... wait a minute. $hit, I am getting into an endless loop here......
I need to draw this out first. Give me a bit.

__________________
"I brew with a water cooler and some part from the toilet." - JohnnyO

"I do gravity feed the last gallon or two through my Therminator, but I expect you could suck start a Volkswagen before you could suck start one of these. - GilaMinumBeer

"..... Bull was right." - TXCurtis
bull8042 is offline

Reply With Quote Quick reply to this message
Old 02-05-2009, 12:40 AM   #15
bull8042
I like 'em shaved
Feedback Score: 0 reviews

bull8042's Avatar
Recipes

Join Date: Jul 2008
Location: Fort Mill, SC
Posts: 10,279
Liked 445 Times on 443 Posts
Likes Given: 11

Default

OK, let's see if I can explain this. Sorry for the crappy drawing, but I just threw it together.
When you apply power, Timer A begins timing. After 5 minutes, it switches "on" and stays on. That will turn on your valve and start the Timer B. After 1 minute, Timer B will change states and both timers will switch off instantaneously, allowing the NC contact "B" to close and start the timing cycle of Timer A again. Both timers are "ON" delay, meaning they will time for their set time before switching....
Is this clear as mud?

__________________
"I brew with a water cooler and some part from the toilet." - JohnnyO

"I do gravity feed the last gallon or two through my Therminator, but I expect you could suck start a Volkswagen before you could suck start one of these. - GilaMinumBeer

"..... Bull was right." - TXCurtis
bull8042 is offline

Reply With Quote Quick reply to this message
Old 02-05-2009, 12:54 AM   #16
babalu87
Feedback Score: 0 reviews
Recipes

Join Date: Feb 2008
Location: Middleborough, MA
Posts: 1,914
Liked 8 Times on 7 Posts
Likes Given: 12

Default

Quote:
Originally Posted by GilaMinumBeer View Post
I believe the Kaiser prefers the Reininhisboat.

I do too.
My thought, besides tradition is why the hell should I pay for something to keep the foaming action of my yeast down when I can just get a bigger fermenter?
__________________
babalu87 is offline

Reply With Quote Quick reply to this message
Old 02-05-2009, 01:04 AM   #17
bull8042
I like 'em shaved
Feedback Score: 0 reviews

bull8042's Avatar
Recipes

Join Date: Jul 2008
Location: Fort Mill, SC
Posts: 10,279
Liked 445 Times on 443 Posts
Likes Given: 11

Default

Quote:
Originally Posted by babalu87 View Post
I do too.
My thought, besides tradition is why the hell should I pay for something to keep the foaming action of my yeast down when I can just get a bigger fermenter?
Sure. I ferment my 10 gal batches in one of these and have never had a blowoff yet!

__________________
"I brew with a water cooler and some part from the toilet." - JohnnyO

"I do gravity feed the last gallon or two through my Therminator, but I expect you could suck start a Volkswagen before you could suck start one of these. - GilaMinumBeer

"..... Bull was right." - TXCurtis
bull8042 is offline

Reply With Quote Quick reply to this message
Old 02-05-2009, 11:13 AM   #18
babalu87
Feedback Score: 0 reviews
Recipes

Join Date: Feb 2008
Location: Middleborough, MA
Posts: 1,914
Liked 8 Times on 7 Posts
Likes Given: 12

Default

Quote:
Originally Posted by bull8042 View Post
Sure. I ferment my 10 gal batches in one of these and have never had a blowoff yet!

You havent used Wyeast 1007 yet have you
__________________
babalu87 is offline

Reply With Quote Quick reply to this message
Old 02-05-2009, 02:01 PM   #19
pjj2ba
Look under the recliner
Feedback Score: 0 reviews

pjj2ba's Avatar
Recipes

Join Date: Jul 2006
Location: State College, Pennsylvania
Posts: 3,427
Liked 195 Times on 161 Posts
Likes Given: 22

Default

I have just what you are looking for. I use mine to run a mister for my houseplants. I have it set to go off for 5 min. about every 1.5 hours during the day. It is digital. I can't remember the brand. I'll check tonight at home. I'd swore I bought it at Lowes, but I don't see it on their website.

I did find this one though at $23
digital timer

__________________
On Tap: Ger. Pils, OKZ (std Amer. lager), CZ Pils, Maibock,
Kegged and Aging/Lagering:CAP, CAP II, Wheat lager, Imperial Pilsner, Ger. Pils, OKZ (std Amer. lager), OKZ II (for base malt comparison), light beer - yes, light beer, Belgian IPA, IPA,
Secondary:
Primary: Pale Ale
Brewing soon: Saison
Recently kicked : ( IPA, Bock, Saison,
Pilsner Urquell Master Homebrewer
(1st NYC 2011, 2nd NYC 2012)
P U crowns winners in its inaugural master HB competition
pjj2ba is offline

Reply With Quote Quick reply to this message
Old 02-05-2009, 04:10 PM   #20
Kaiser
Feedback Score: 0 reviews

Kaiser's Avatar
Recipes

Join Date: Nov 2005
Location: Pepperell, MA
Posts: 3,904
Liked 114 Times on 71 Posts
Likes Given: 4

Default

Quote:
Originally Posted by pjj2ba View Post
II have it set to go off for 5 min. about every 1.5 hours during the day.
How did you progam this? Did you program the countdown timer or did you program tha actual time of the day when it should go on/off?

Kai
__________________
BrauKaiser.com - brewing science blog - Twitter - water and mash chemistry calculator
Kaiser is offline

Reply With Quote Quick reply to this message
