Old 03-31-2013, 04:36 AM   #281
Transamguy77
Feedback Score: 0 reviews
Recipes

Join Date: Apr 2011
Location: Quakertown, Pa
Posts: 736
Liked 38 Times on 35 Posts
Likes Given: 10

Default

Quote:
Originally Posted by Fordzilla

Is a powered corona mill even worth the effort? Seems like no one goes that route.















Here are some pics of my motorized Corona mill at this point I've been using it for almost a year and have run prob 500+ lbs of grain through it with no problems.
__________________
Transamguy77 is offline

Reply With Quote Quick reply to this message
Old 03-31-2013, 08:42 PM   #282
Hunky
Feedback Score: 0 reviews
Recipes

Join Date: Aug 2012
Location: Nome, AK
Posts: 37
Likes Given: 14

Default

I've got a couple 1/2" electric drills in stock and a speed reducer coming so will give that a shot until I rig up something a bit better.

I'm curious what kind of forces would be on a 12" sheave (pulley). I'm thinking I could build one out of 3/4" plywood since buying one seems to be in the neighborhood of $37 plus about $30 in shipping (I'm rural Alaska). My lathe motor is 1725 rpm and has a 2" pulley as smallest diameter on a cluster of larger pulleys.

/jd

__________________
Hunky is offline

Reply With Quote Quick reply to this message
Old 04-01-2013, 12:23 AM   #283
jeepinjeepin
Feedback Score: 1 reviews
Recipes

Join Date: Apr 2011
Location: Winston-Salem, NC
Posts: 6,391
Liked 1043 Times on 1022 Posts
Likes Given: 35

Default

Quote:
Originally Posted by Hunky
I've got a couple 1/2" electric drills in stock and a speed reducer coming so will give that a shot until I rig up something a bit better.

I'm curious what kind of forces would be on a 12" sheave (pulley). I'm thinking I could build one out of 3/4" plywood since buying one seems to be in the neighborhood of $37 plus about $30 in shipping (I'm rural Alaska). My lathe motor is 1725 rpm and has a 2" pulley as smallest diameter on a cluster of larger pulleys.

/jd
3/4" plywood should be more than sufficient. Just use common sense when putting it together. Use wide bases and box it off the make it stiff in all directions.
__________________

Walmart is about the only reason for open or concealed carry that I can get behind. -Randar

jeepinjeepin is offline

Reply With Quote Quick reply to this message
Old 04-01-2013, 03:47 PM   #284
BaldApe
Feedback Score: 0 reviews
Recipes

Join Date: Aug 2008
Location: Calvert County, Maryland, USA
Posts: 30
Likes Given: 2

Default

I have a motor from a grinding wheel my Dad used. It is a 1/4 HP type KH motor rated at 1745 RPM.

I bought two pulleys, a 2 inch and an 11 inch, but I'm worried that the speed reduction won't be enough for my Corona mill to handle.

Can I use a dimmer switch to slow the motor, or will that burn it out?

__________________
BaldApe is offline

Reply With Quote Quick reply to this message
Old 04-01-2013, 09:41 PM   #285
g-love
Feedback Score: 4 reviews
Recipes

Join Date: Jul 2010
Location: Warfordsburg, Pennsylvania
Posts: 686
Liked 100 Times on 80 Posts
Likes Given: 10

Default

Just finished mine today. I have to say that it took me an embarrassingly long time to get the motor leveled and squared up to the mill itself. What a PITA....

Anyway, I haven't run any grain through it yet, but I'm anticipating good things.

I basically stole jpalarchio's design. I like the idea of it being portable and easily hung on a wall, rather than taking up floor space. Thanks J!

malt-mill-1.jpg   malt-mill-2.jpg
__________________
Fermenting - Nada
Bottled/ Kegged - Reaper's Mild
Up Next: a porter
g-love is offline

Reply With Quote Quick reply to this message
Old 04-03-2013, 12:37 AM   #286
lpdjshaw
Feedback Score: 0 reviews
Recipes

Join Date: Jun 2011
Location: North County, San Diego, California
Posts: 358
Liked 15 Times on 14 Posts
Likes Given: 6

Default

Quote:
Originally Posted by Hang Glider View Post
Bodine gearmotor off e-bay, DC, converted to AC. A lovejoy and a right-angle attachment for a power drill - sits on the bucket, goes anywhere, doesn't take up much space. The rpm is low, torque is high, bet it would crush rocks.




the DC to AC converter box I built (with a little help from an electronics forum)
Wow! Gotta mark this one for when I get ready to motorize my mill. Love the very small footprint.
__________________
TIKI Brew
lpdjshaw is offline

Reply With Quote Quick reply to this message
Old 04-03-2013, 12:53 AM   #287
lpdjshaw
Feedback Score: 0 reviews
Recipes

Join Date: Jun 2011
Location: North County, San Diego, California
Posts: 358
Liked 15 Times on 14 Posts
Likes Given: 6

Default

Quote:
Originally Posted by PuckeredPenguin View Post
Here's mine:

After some help from DayTripper and inspiration from ClarnoBrewer I just got finished motorizing my AWESOME Rebel Brewer Mill. This thing is built like a tank and now thats it's powered it has no problem crushing grain!

Thanks to all who have provided me with inspiration and guidance!!
Sweet idea!!!
__________________
TIKI Brew
lpdjshaw is offline

Reply With Quote Quick reply to this message
Old 04-04-2013, 03:53 PM   #288
Irrenarzt
HNIC
Feedback Score: 2 reviews

Irrenarzt's Avatar
Recipes

Join Date: Aug 2009
Location: Half a mile from Tucson
Posts: 1,899
Liked 155 Times on 113 Posts
Likes Given: 91

Default

Here's a old pic of mine.

__________________
On Tap: Belgian Pale Ale, Session Porter, American Brown Ale, Rum Barrel-Aged Wee Heavy, Beer Camp #118 Grandma's Closet

On Deck: Oud Bruin, Blue Corn Saison, Weizenbock, Berliner Weisse, Pomegranate Cider
Irrenarzt is offline

Reply With Quote Quick reply to this message
Old 04-04-2013, 05:01 PM   #289
g-love
Feedback Score: 4 reviews
Recipes

Join Date: Jul 2010
Location: Warfordsburg, Pennsylvania
Posts: 686
Liked 100 Times on 80 Posts
Likes Given: 10

Default

Quote:
Originally Posted by Irrenarzt View Post
Here's a old pic of mine.
Ooooooh. Shiny!
__________________
Fermenting - Nada
Bottled/ Kegged - Reaper's Mild
Up Next: a porter
g-love is offline

Reply With Quote Quick reply to this message
Old 04-04-2013, 10:54 PM   #290
day_trippr
Feedback Score: 0 reviews
Recipes

Join Date: May 2011
Location: Stow, MA
Posts: 10,311
Liked 1229 Times on 994 Posts

Default

Quote:
Originally Posted by Irrenarzt View Post
Here's a old pic of mine.
Nice build!

Is that a clapped-out M in the background?

Cheers!
__________________
day_trippr is online now

Reply With Quote Quick reply to this message
