Default Conical Project - Feedback Requested

I designed this side by side 7 gallon SS conicle system. The drawings are at the machine shop but I still have time to make changes. Any suggestions by current conicle owners???

It has a polycarbonate lid that will allow me to watch all the fun going on inside. Destaco clamps push the lid into a silicon gasket. 3/4 NPT threads on the lid for pressure fittings or blow off tube. The frame is tube SS. Instead of one big conicle, I went with 2 smaller ones that will allow me to do some experimentation on split batches.


__________________
Keg 1 : Belgian IPA
Keg 2 : Oktoberfest Lager (currently lagering)
Keg 3 : Tap Cleaning Fluid
Keg 4 :
Conical Left:
Conical Right:American Wheat (7-day G2G)
On Deck: Pumpkin Ale, Apocalypso Ale (AHB)

"Save your sack; Brew in a Bag"
McTarnamins is offline

Reply With Quote Quick reply to this message
Old 08-31-2007, 01:20 PM   #2
ohiobrewtus
Feedback Score: 0 reviews

ohiobrewtus's Avatar
Recipes

Join Date: Nov 2006
Location: Ohio
Posts: 7,814
Liked 37 Times on 35 Posts
Likes Given: 4

Default

I do not own a conical so I can't offer any advice, but I will tell you that your design looks freaking sweet!

__________________
Quote:
Originally Posted by the_bird
Well, if you *love* it.... again, note that my A.S.S. has five pounds.
ohiobrewtus is offline

Reply With Quote Quick reply to this message
Old 08-31-2007, 01:56 PM   #3
Ryan_PA
Feedback Score: 0 reviews
Recipes

Join Date: Aug 2006
Location: South Philly, Pennsylvania
Posts: 1,913
Liked 7 Times on 5 Posts
Likes Given: 1

Default

I do not own a conical, but if I were contracting someone to build this I would ensure the legs are high enough for racking directly to the keg. Also, are you certain that the two clams are enough for a good seal?

Cool design.

__________________
Ryan_PA is offline

Reply With Quote Quick reply to this message
Old 08-31-2007, 06:11 PM   #4
Llarian
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2006
Location: Seattle, WA
Posts: 276
Liked 3 Times on 1 Posts

Default

Quote:
Originally Posted by Ryan_PA
Also, are you certain that the two clams are enough for a good seal?

Cool design.
No, I certain a good seal needs far more than two clams to maintain a healthy diet. =)





-D
__________________
Llarian is offline

Reply With Quote Quick reply to this message
Old 08-31-2007, 06:33 PM   #5
kvh
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2005
Location: Baltimore, MD
Posts: 343
Default

Quote:
Originally Posted by Llarian
No, I certain a good seal needs far more than two clams to maintain a healthy diet. =)



-D
*chuckle*

tragic, this post is already off topic.

still funny though.

kvh.
__________________
Make beer, not bombs.
(...and not bottle bombs either.)
Primary Fermentor - *empty*
Primary Fermentor -

Secondary - Mystery IPA
Secondary -
Bottle Conditioning -
Keg Conditioning -

Draft: - Apfelwein, Belgian-style Dubbel w/ Grains of Paradise
Bottles:(and still in stock): FIRST AG - (I)IPA 4.1.07, PK's Warm Spring Marzen, Summer Cerveza -BANG, PK's Winter Spice II, Espresso Stout, Indiana Pale Ale, PK's Chocolate Bitter II, Porterfield Porter, and New Year's 2006 remnants.

kvh is offline

Reply With Quote Quick reply to this message
Old 09-04-2007, 02:04 PM   #6
Yorg
Feedback Score: 0 reviews
Recipes

Join Date: Jun 2007
Posts: 168
Liked 1 Times on 1 Posts

Default How much

How much have you been quoted to fabricate this?

__________________
Yorg is offline

Reply With Quote Quick reply to this message
Old 09-04-2007, 02:32 PM   #7
Bobby_M
Vendor and Brewer
Vendor Ads
Feedback Score: 2 reviews

Bobby_M's Avatar
Recipes

Join Date: Aug 2006
Location: Whitehouse Station, NJ
Posts: 22,015
Liked 978 Times on 653 Posts
Likes Given: 28

Default

My biggest concern with a single piece this large is the inability for temp control. I'd rather have each conical on it's own compact stand that would fit into a fridge.

I suspect you could go with a ringed tripod design using much smaller stock and have each on their own stands. Much more flexibility IMHO.

__________________
BrewHardware.com
Sightglass, Refractometer, Ball Valve, Weldless bulkhead, Thermometer, Decals, Stainless Steel Fittings, Compression Fittings, Camlock Quick Disconnects, Scale, RIMS tube, Plate Chiller, Chugger Pump, Super Clear Silicone Tubing, and more!

New Stuff?
Bobby_M is online now

Reply With Quote Quick reply to this message
Old 09-05-2007, 03:31 AM   #8
McTarnamins
Feedback Score: 0 reviews

McTarnamins's Avatar
Recipes

Join Date: Feb 2007
Location: St. Louis
Posts: 254
Liked 2 Times on 2 Posts
Likes Given: 2

Default

It's hard to tell by the design, but each of the conicals can be removed from the stand. I have a spare fridge that I can put one into on a smaller stand for lagering. I have a basement that is always 62-68° so it is perfect for ales. My idea for two 7 gallon fermenters was for side by side testing. Split worts, different yeast, etc....

To answer another question, I traded some other hardware to the machine shop owner for some fabrication work so I do not know the actual cost. My estimate would be around $1200 for complete fabrication. I bought the fittings, gaskets, and other ancillary components. If you want the drawings, send me your e-mail and I'll give you the drawings for free. You can just give them to any machine shop and they can make the conicals. Not really cost effective, but it was the best option for me since I traded some other hardware. Plus it was fun to design my semi-ultimate system. I am a mechanical engineer but I do freelance design and drafting on the side.

I have actual pictures that I will post soon. It looks friggn awesome IMHO.

Thanks for the input.

__________________
Keg 1 : Belgian IPA
Keg 2 : Oktoberfest Lager (currently lagering)
Keg 3 : Tap Cleaning Fluid
Keg 4 :
Conical Left:
Conical Right:American Wheat (7-day G2G)
On Deck: Pumpkin Ale, Apocalypso Ale (AHB)

"Save your sack; Brew in a Bag"
McTarnamins is offline

Reply With Quote Quick reply to this message
Old 09-16-2010, 05:39 AM   #9
BrewBeemer
Feedback Score: 0 reviews
Recipes

Join Date: Feb 2006
Location: an island, inside an atoll
Posts: 3,504
Liked 20 Times on 20 Posts
Likes Given: 7

Default

Your PM is filled, I sent a PM for your blueprints on your conicals with my email address. many thanks in advance. Carl.

__________________
BrewBeemer is offline

Reply With Quote Quick reply to this message
Old 09-16-2010, 01:53 PM   #10
Cpt_Kirks
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2008
Location: Lakeland TN
Posts: 3,738
Liked 44 Times on 39 Posts

Default

Quote:
Originally Posted by Bobby_M View Post
My biggest concern with a single piece this large is the inability for temp control. I'd rather have each conical on it's own compact stand that would fit into a fridge.
Glycol, tubing and a freezer for the glycol reservoir. There was a sweeeeet design in Zymurgy a few months back.
