Default Building a copper manifold

.. for my mash tun.. Got all the 90's and Tee's laid out, cutting the tubing...

Couple questions.. How wide should the slits be? I know many people use hack saws, but I was hoping to use my dremel tool or peanut grinder with a cutoff wheel...

The cut off wheels I have for my peanut grinder are 3/64" thick.. Would probably make a cut that is 1/16".. I think the dremel blade is slightly thinner yet...

Also, I plan to use a short piece of 1/2" silicone tubing to connect the manifold to the outlet.. Can I use 'nylon' barbs? Or do they have to be stainless or brass? Will the nylon barbs handle the heat? With this set up, I'm thinking I won't need hose clamps.. or should I use them anyways?

__________________
"DOH!"
Homer Simpson


"Beer is living proof that God loves us, and wants us to be happy."
(possibly said by) Ben Franklin (maybe)


Quote:
Originally Posted by arturo7 View Post
Damn, where's my arm?.

"You can pick your nose, and you can pick your friends... but you can't pick your friends nose!"
George Carlin
r8rphan is offline

Reply With Quote Quick reply to this message
Old 12-16-2010, 11:42 PM   #2
Flyin
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2009
Location: Holland, MI
Posts: 98
Liked 2 Times on 2 Posts

Default

Those cutoff wheels should be fine. I'm not sure about the nylon. Silicon hose will be OK w/o clamps as long as the manifold can't come disconnected if it gets bumped while stirring the mash.

__________________
Flyin is offline

Reply With Quote Quick reply to this message
Old 12-17-2010, 04:02 PM   #3
FishFace
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2010
Location: GranitBay, CA
Posts: 77
Default

Use the thin red cutting disks. They make skinnier slits, a slit every inch. Not too deep, you can always deepen, but you can't take the cut back!

Mine sucks the bottom of the MLT dry!

__________________
FishFace is offline

Reply With Quote Quick reply to this message
Old 12-17-2010, 04:03 PM   #4
FishFace
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2010
Location: GranitBay, CA
Posts: 77
Default

Nylon will not handle heat!

__________________
FishFace is offline

Reply With Quote Quick reply to this message
Old 12-17-2010, 04:37 PM   #5
Baron von BeeGee
Beer Bully
Feedback Score: 0 reviews

Baron von BeeGee's Avatar
Recipes

Join Date: Jul 2005
Location: Barony of Fuquay-Varina, NC
Posts: 5,419
Liked 10 Times on 10 Posts

Default

Dremels work great.

I would avoid nylon. For mine, I attached a copper male connector to the outlet and a female to the manifold. I just pressure fit them while mashing which works fine and makes removal pretty trivial.

__________________
Baron von BeeGee is offline

Reply With Quote Quick reply to this message
Old 12-17-2010, 04:56 PM   #6
BendBrewer
Feedback Score: 0 reviews
Recipes

Join Date: Jan 2010
Location: Bend, Oregon
Posts: 3,169
Liked 69 Times on 55 Posts
Likes Given: 23

Default

I understand the fear associated with using nylon but I use a nylon barb in mine with no ill effects.

I cut about a 2 inch piece of the copper pipe and shoved it over the barb. Snug fit. My manifold simply attaches to that.

__________________
BendBrewer is offline

Reply With Quote Quick reply to this message
Old 12-17-2010, 05:24 PM   #7
mariojr
Feedback Score: 0 reviews
Recipes

Join Date: Nov 2008
Location: Raleigh,NC
Posts: 310
Liked 7 Times on 5 Posts
Likes Given: 158

Default

I connected mine with a length of PEX tubing. It fits snugly into 1/2 fittings and can bend a bit if you need it to.

__________________
-----

Mario


A Flower?
mariojr is offline

Reply With Quote Quick reply to this message
Old 12-17-2010, 09:42 PM   #8
r8rphan
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2010
Location: Shingletown, CA
Posts: 1,717
Liked 21 Times on 21 Posts
Likes Given: 8

Default

Quote:
Originally Posted by mariojr View Post
I connected mine with a length of PEX tubing. It fits snugly into 1/2 fittings and can bend a bit if you need it to.

Hey, I'll have to check that out.. I have miles of that stuff laying around...

Did you guys sweat your manifold fittings and tube together, or will it all stay intact without solder?
__________________
"DOH!"
Homer Simpson


"Beer is living proof that God loves us, and wants us to be happy."
(possibly said by) Ben Franklin (maybe)


Quote:
Originally Posted by arturo7 View Post
Damn, where's my arm?.

"You can pick your nose, and you can pick your friends... but you can't pick your friends nose!"
George Carlin
r8rphan is offline

Reply With Quote Quick reply to this message
Old 12-17-2010, 10:33 PM   #9
2morrow
Feedback Score: 0 reviews
Recipes

Join Date: Jul 2010
Location: Morganton, NC
Posts: 30
Default

Mine will stay together without soldering. I will 2nd the dremel tool as well, makes it really easy and quick.

__________________
2morrow is offline

Reply With Quote Quick reply to this message
Old 12-17-2010, 10:42 PM   #10
mariojr
Feedback Score: 0 reviews
Recipes

Join Date: Nov 2008
Location: Raleigh,NC
Posts: 310
Liked 7 Times on 5 Posts
Likes Given: 158

Default

Quote:
Originally Posted by 2morrow View Post
Mine will stay together without soldering. I will 2nd the dremel tool as well, makes it really easy and quick.
Ditto. It stays together pretty well without soldering and I have mine built so it fits tight in the cooler.
__________________
-----

Mario


A Flower?
mariojr is offline
