Default How to measure wort in kettle?

How do you guys measure your wort while in the brew kettle to know when you have hit your volume or need to top up, etc? First AG on Sat. looking for pointers.

__________________
ChadChaney is offline

Reply With Quote Quick reply to this message
Old 02-17-2012, 04:49 PM   #2
happypanties
Feedback Score: 0 reviews
Recipes

Join Date: Nov 2011
Location: Cleveland, OH
Posts: 103
Likes Given: 33

Default

I pre-measured my spoon before brewing my first AG batch. Just add a half gallon of water, mark the spoon with a sharpie, add another half gallon, make another mark, etc... until you get to the top of the pot.

Then when brewing, use the spoon to tell you how much wort you have.

__________________
happypanties is offline

Reply With Quote Quick reply to this message
Old 02-17-2012, 04:51 PM   #3
weirdboy
Feedback Score: 3 reviews
Recipes

Join Date: May 2009
Location: Los Angeles
Posts: 7,901
Liked 423 Times on 344 Posts
Likes Given: 57

Default

Get yourself a cheapo yardstick from e.g. Home Depot.


Measure the inside diameter of your kettle, in inches. Try to be as accurate as you can on this number.
Calculate the surface area of your vessel. The forumla is:

R = 1/2 * diameter
Pi*R^2

That number also happens to be the number of cubic inches in your kettle, per inch of height.

There are 231 cubic inches in a gallon.

So, the number of inches per gallon (I will call this N) in your kettle is:

N = 231 / (Pi * R^2)

Now, look at the yardstick, and on the back side, mark off with a permanent marker every N inches as a gallon mark. If you want to do half or quarter gallons, that is easy enough...




There is no sense wasting a bunch of water to measure the volume of something that is easy enough to calculate.

__________________
weirdboy is offline
Naggs Likes This
Reply With Quote Quick reply to this message
Old 02-17-2012, 04:52 PM   #4
happypanties
Feedback Score: 0 reviews
Recipes

Join Date: Nov 2011
Location: Cleveland, OH
Posts: 103
Likes Given: 33

Default

LOL yes I was thinking of doing it that way too, but didn't want to do all the math

__________________
happypanties is offline

Reply With Quote Quick reply to this message
Old 02-17-2012, 05:01 PM   #5
Brew-ta-sauraus
Feedback Score: 0 reviews
Recipes

Join Date: Oct 2008
Location: Parker, CO
Posts: 324
Liked 4 Times on 4 Posts
Likes Given: 1

Default

Quote:
Originally Posted by happypanties View Post
I pre-measured my spoon before brewing my first AG batch. Just add a half gallon of water, mark the spoon with a sharpie, add another half gallon, make another mark, etc... until you get to the top of the pot.

Then when brewing, use the spoon to tell you how much wort you have.
I did the same as above only in 1 gal increments. Etched my paddle with the marks.
__________________
Brew-ta-sauraus is offline

Reply With Quote Quick reply to this message
Old 02-17-2012, 05:02 PM   #6
Brew-ta-sauraus
Feedback Score: 0 reviews
Recipes

Join Date: Oct 2008
Location: Parker, CO
Posts: 324
Liked 4 Times on 4 Posts
Likes Given: 1

Default

Quote:
Originally Posted by weirdboy View Post
Get yourself a cheapo yardstick from e.g. Home Depot.


Measure the inside diameter of your kettle, in inches. Try to be as accurate as you can on this number.
Calculate the surface area of your vessel. The forumla is:

R = 1/2 * diameter
Pi*R^2

That number also happens to be the number of cubic inches in your kettle, per inch of height.

There are 231 cubic inches in a gallon.

So, the number of inches per gallon (I will call this N) in your kettle is:

N = 231 / (Pi * R^2)

Now, look at the yardstick, and on the back side, mark off with a permanent marker every N inches as a gallon mark. If you want to do half or quarter gallons, that is easy enough...




There is no sense wasting a bunch of water to measure the volume of something that is easy enough to calculate.
FYI I didnt waste the water I transferred it to my HLT for the next day brewing. Guess I could have gone the math route as well but I bored and needed to kill some time.
__________________
Brew-ta-sauraus is offline

Reply With Quote Quick reply to this message
Old 02-17-2012, 06:22 PM   #7
TheMan
Feedback Score: 20 reviews

TheMan's Avatar
Recipes

Join Date: May 2009
Location: Illinois
Posts: 2,905
Liked 312 Times on 234 Posts
Likes Given: 2

Default

I don't really measure mine anymore. After you get your system dialed in you should have almost exact volumes at the end of the boil every time. After my first few boils I measured the amount left and found that I boil off a gallon every half hour. So I start with 7.5 gallons to have my planned 5.5 gallons.

Every once in a while I measure just to see. And every time I have 5.5 gallons give or take 1/4 gallon tops.

__________________
TheMan is offline

Reply With Quote Quick reply to this message
Old 02-17-2012, 06:32 PM   #8
Calichusetts
Feedback Score: 0 reviews

Calichusetts's Avatar
Recipes

Join Date: Nov 2011
Location: Plymouth, MA
Posts: 2,312
Liked 221 Times on 162 Posts
Likes Given: 592

Default

Use a lab thermometer and kill two birds with one stone. Either take measurements from when the thermometer is sitting on the bottom or hanging from the top or both. I can measure my volume to the hundreth of a gallon with ease...not that I need to

__________________
Calichusetts is offline

Reply With Quote Quick reply to this message
Old 02-17-2012, 06:35 PM   #9
snevey
Feedback Score: 0 reviews
Recipes

Join Date: Jan 2009
Location: Dover, PA
Posts: 294
Liked 3 Times on 3 Posts
Likes Given: 15

Default

I have a notched aluminum "dowel rod" that I have marked in .5 gallon increments.

__________________
snevey is offline

Reply With Quote Quick reply to this message
Old 02-17-2012, 07:25 PM   #10
Snafu
Feedback Score: 0 reviews

Snafu's Avatar
Recipes

Join Date: Apr 2009
Location: Richmond, VA
Posts: 1,010
Liked 15 Times on 13 Posts
Likes Given: 2

Default

I use a 4 foot 1 1/4" oak dow rod. I used a wood burning tool to "mark" every 1/2 gal. up to 13 gals.

__________________
I have vessels, some contain beer.

Last edited by Snafu; 02-17-2012 at 07:30 PM. Reason: added photo
