Old 11-04-2010, 01:42 PM   #11
Cpt_Kirks
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2008
Location: Lakeland TN
Posts: 3,738
Liked 44 Times on 39 Posts

Default

Quote:
Originally Posted by JoeBuch View Post
What were the costs to build with wood? What were were your dimensions?
I used 1/2" B/C plywood and framing 2x4's. Cost for wood and wood screws was about $35. I had some small nails I used to attach the plywood on hand. The paint (primer and interior/exterior latex) cost about $15.

Dimensions (if I remember right) are 60" long, 24" deep, and 20" high. The casters will add about 4", giving me a top deck 24.5" or so high.

I wanted it low for easy keggle access, but enough height to give me about 18" of drop to the pump.
__________________
Cpt_Kirks is offline

Reply With Quote Quick reply to this message
Old 11-04-2010, 02:48 PM   #12
Tiber_Brew
It's about the beer.
Feedback Score: 0 reviews

Tiber_Brew's Avatar
Recipes

Join Date: Apr 2010
Location: Upper Peninsula, Michigan
Posts: 2,054
Liked 94 Times on 71 Posts
Likes Given: 139

Default

I built mine. Cost me about $100 for the 1.5" sq steel tubing. I'm getting it powder coated for $40.

TB

Quote:
Originally Posted by Tiber_Brew View Post
I also got my brew stand welded up this weekend...

Cutting the steel 1.5" x 1.5" steel tubing:


I made a model and drawing in Unigraphics NX beforehand, and that made the build go much smoother:


Welding the top frame:


C-clamps come in handy:


Try not to look directly into the arc...or my bald spot:


I designed and fabricated a method for holding my large counterflow chiller. Here's some of it in progress:


Works like a charm:




Here's the final mockup. I still need to get it powder coated and mount the pumps:





TB
__________________
On tap:
1. Bourbon Barrel Imperial Oatmeal Stout 2. Oktoberfest 3. IPA 4. Bohemian Pilsner 5.[Nitrogen] Dry Stout
Primary:
1. Ger Pils 2. Ger Pils 3. Lambic 4. Lambic 5. none 6. none
Secondary:
1. Brett Ale 2. Ger Pils 3. Ger Pils 4. none
Bottled:
About 36 gallons of beer & 4.2 gallons of mead
Kegged & conditioning:
Breakfast Stout x2, Belgian Dubbel, Chocolate Milk Stout, Oktoberfest (lagering), Pale Ale x2
Tiber_Brew is offline

Reply With Quote Quick reply to this message
Old 11-04-2010, 05:40 PM   #13
SweetSounds
Feedback Score: 1 reviews
Recipes

Join Date: Jan 2010
Location: Des Moines, Iowa
Posts: 1,429
Liked 18 Times on 17 Posts
Likes Given: 4

Default

+1 on the stainless tables. I bought a 4' and a 5' for $150 on CL. I'm going to sell the 4' for $100 or so and recoup some of that = $50 stainless steel brew stand

__________________
Quote:
Originally Posted by Ecnerwal View Post
What does the primary pressure gauge on the tank tell us? That's right, the temperature. Put it on a scale if you want to know how much is in it...
Put some duct tape over the gauge - Or better yet - Replace the high pressure gauge with a plug - High pressure gauges are useless!
SweetSounds is offline

Reply With Quote Quick reply to this message
Old 11-04-2010, 08:12 PM   #14
JayInJersey
Feedback Score: 0 reviews
Recipes

Join Date: May 2009
Location: New Jersey
Posts: 600
Liked 1 Times on 1 Posts
Likes Given: 2

Default

wood is sexier than stainless...

__________________
Hazard Brewing
JayInJersey is offline

Reply With Quote Quick reply to this message
Old 01-17-2011, 03:35 PM   #15
ranchonodinero
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2010
Location: DFW, TX
Posts: 52
Liked 1 Times on 1 Posts
Likes Given: 1

Default wire and gas?

What wire, size, and gas did you use for your stainless? I've got a mig setup but have never tried stainless with it.

Thanks!

Quote:
Originally Posted by Tiber_Brew View Post
I built mine. Cost me about $100 for the 1.5" sq steel tubing. I'm getting it powder coated for $40.

TB
__________________
ranchonodinero is offline

Reply With Quote Quick reply to this message
Old 01-17-2011, 03:47 PM   #16
Tiber_Brew
It's about the beer.
Feedback Score: 0 reviews

Tiber_Brew's Avatar
Recipes

Join Date: Apr 2010
Location: Upper Peninsula, Michigan
Posts: 2,054
Liked 94 Times on 71 Posts
Likes Given: 139

Default

Quote:
Originally Posted by ranchonodinero View Post
What wire, size, and gas did you use for your stainless? I've got a mig setup but have never tried stainless with it.

Thanks!
I used mild steel, not stainless. I can still try to find the welder settings if you want. I do remember that I used flux core instead of gas.

TB
__________________
On tap:
1. Bourbon Barrel Imperial Oatmeal Stout 2. Oktoberfest 3. IPA 4. Bohemian Pilsner 5.[Nitrogen] Dry Stout
Primary:
1. Ger Pils 2. Ger Pils 3. Lambic 4. Lambic 5. none 6. none
Secondary:
1. Brett Ale 2. Ger Pils 3. Ger Pils 4. none
Bottled:
About 36 gallons of beer & 4.2 gallons of mead
Kegged & conditioning:
Breakfast Stout x2, Belgian Dubbel, Chocolate Milk Stout, Oktoberfest (lagering), Pale Ale x2
Tiber_Brew is offline

Reply With Quote Quick reply to this message
Old 01-17-2011, 04:18 PM   #17
ranchonodinero
Feedback Score: 0 reviews
Recipes

Join Date: Dec 2010
Location: DFW, TX
Posts: 52
Liked 1 Times on 1 Posts
Likes Given: 1

Default

Looks great-I'm already set up for mild steel, but have wanted to try stainless. I've got 2 different recommendations for gas-one guy says trimix. I've already got Argon CO2 gas.

__________________
ranchonodinero is offline

Reply With Quote Quick reply to this message
Old 01-17-2011, 06:39 PM   #18
mcgeebc
Feedback Score: 0 reviews
Recipes

Join Date: Jan 2007
Location: Cleveland, OH
Posts: 90
Liked 2 Times on 2 Posts

Default

For those of you with wood stands, what do you use for the top? Plywood? Anyone use laminate counters or anything else interesting?

__________________
mcgeebc is offline

Reply With Quote Quick reply to this message
Old 01-18-2011, 12:35 AM   #19
MilwaukeeBrewGuy
Feedback Score: 0 reviews
Recipes

Join Date: Apr 2008
Posts: 344
Default

For 275 dollars out the door, this seems like a deal. 2 pump mounts and a control panel mount.
Just ordered mine. http://www.brewersequipment.com/elec...d_special.html

__________________
MilwaukeeBrewGuy is offline

Reply With Quote Quick reply to this message
Old 01-18-2011, 02:35 AM   #20
ScubaSteve
Feedback Score: 0 reviews

ScubaSteve's Avatar
Recipes

Join Date: May 2007
Location: New Bern, NC
Posts: 3,674
Liked 62 Times on 46 Posts
Likes Given: 11

Default

For that price its worth going with SS...the maintenance on mild steel will cost the difference over a few years.....

__________________
UNIBREW 5500 SINGLE VESSEL BREWERY
WOODEN SINGLE TIER
ScubaSteve is offline
