Old 08-23-2012, 05:27 PM   #51
porcupine73
Feedback Score: 0 reviews
Recipes

Join Date: Aug 2012
Location: Fort Meade
Posts: 811
Liked 45 Times on 41 Posts
Likes Given: 513

Default

Looks very nice. The wiring is pretty neat and tidy. The lamicoid nameplates really add a professional touch. Is a ground bonding jumper required for the door?

__________________
porcupine73 is offline

Reply With Quote Quick reply to this message
Old 08-23-2012, 05:40 PM   #52
bolts
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2009
Location: Portland, OR
Posts: 306
Liked 8 Times on 7 Posts
Likes Given: 3

Default

Quote:
Originally Posted by porcupine73 View Post
Looks very nice. The wiring is pretty neat and tidy. The lamicoid nameplates really add a professional touch. Is a ground bonding jumper required for the door?
Thanks -- the tags are from Signs Banners & Tags place Kal recommends. George was nice to work with and had a quick turnaround.

It's hard to see, but there is a grounding post in the top right on the back of the door that's connected to the ground bus bar. Same with the inside right of the box. During testing I confirmed I had continuity between the door, panel, heatsink and backpanel. I used star lock washers in most places to give some bite to ground the various fasteners.
__________________
bolts is offline

Reply With Quote Quick reply to this message
Old 08-23-2012, 05:47 PM   #53
JordanThomas
Feedback Score: 0 reviews
Recipes

Join Date: Jul 2012
Location: Grand Rapids, Michigan
Posts: 889
Liked 82 Times on 77 Posts
Likes Given: 426

Default

Quote:
Originally Posted by SweetSounds View Post
IT'S SO FLUFFY!

HAHA yes. Monsters, Inc. quote. It's a good thing.
__________________
JordanThomas is offline

Reply With Quote Quick reply to this message
Old 08-23-2012, 07:07 PM   #54
jpc
Feedback Score: 0 reviews
Recipes

Join Date: Jan 2009
Location: Santa Clara, CA
Posts: 1,910
Liked 60 Times on 45 Posts

Default

Quote:
Originally Posted by JordanThomas View Post
HAHA yes. Monsters, Inc. quote. It's a good thing.
No, no, no.... Despicable Me!
__________________
jpc is offline
JordanThomas Likes This
Reply With Quote Quick reply to this message
Old 08-24-2012, 07:58 PM   #55
vinylicious
addicted.
Feedback Score: 0 reviews

vinylicious's Avatar
Recipes

Join Date: Oct 2011
Location: Buffalo, NY
Posts: 53
Liked 1 Times on 1 Posts
Likes Given: 2

Default

Bolt - did you ever wire in the alarm? I don't see it in your latest wiring diagram and none of your progress photos show the alarm wired up. T

Thanks by the way, I am basically planning on copying your design for my control panel.

__________________
vinylicious is offline

Reply With Quote Quick reply to this message
Old 08-24-2012, 10:12 PM   #56
bolts
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2009
Location: Portland, OR
Posts: 306
Liked 8 Times on 7 Posts
Likes Given: 3

Default

Quote:
Originally Posted by vinylicious View Post
Bolt - did you ever wire in the alarm? I don't see it in your latest wiring diagram and none of your progress photos show the alarm wired up.

Thanks by the way, I am basically planning on copying your design for my control panel.
I didn't wire up the alarm (at least not yet). It's really there as a placeholder for future use. I'll probably wire it up to my hlt pid so to monitor mash temp from afar. e.g. pump stops, stuck mash, etc would show up as dropping temp in the recirc probe.

I have some ambitious plans to create a timer/alarm module (embedded arduino or netduino). If you do decide to use the alarm without an additional embedded controller, then I would be inclined to follow Kal's lead here and use a switch + alarm (this one is a single unit for light + sound). I wasn't a fan of this given how many extra switches were required, but it works. http://www.theelectricbrewery.com/co...part-2?page=12


I should have a bill-of-materials and my "what I would do differently" thoughts up this weekend.
__________________
bolts is offline

Reply With Quote Quick reply to this message
Old 08-26-2012, 08:00 PM   #57
Cacaman
Feedback Score: 0 reviews

Cacaman's Avatar
Recipes

Join Date: Jan 2011
Location: Laredo, TX
Posts: 516
Liked 9 Times on 9 Posts
Likes Given: 7

Default

Quote:
Originally Posted by bolts View Post
I should have a bill-of-materials and my "what I would do differently" thoughts up this weekend.
Anxiously waiting for this
__________________
Cacaman cheap keezer build!

Quote:
Originally Posted by BierMuncher View Post

“Get your beer off the yeast cake on day 7 or your beer will crawl out of the fermenter and eat your youngest child”

“Your beer will be the equivalent of rhinoceros urine unless it sits on the primary yeast cake for at least 4 weeks.”
Cacaman is online now

Reply With Quote Quick reply to this message
Old 08-27-2012, 05:40 AM   #58
bolts
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2009
Location: Portland, OR
Posts: 306
Liked 8 Times on 7 Posts
Likes Given: 3

Default

First a few more pics. The bench is finished, sink is plumbed and I did a few dry-runs -- including hops in the boil kettle. I had a pump apparently trip a thermal overload, but round #2 of testing didn't have any issues. Mike from chugger offered to send a replacement however. I did a full disassembly and reassembly of the pumps before testing the second time. I had some cavitation issues when pumping while at full boil -- but that seems to be expected. On to the pictures...

Test #1 was some sous vide rib eye steak I had some temp problems while the PID was seemingly tuning itself (it overshot by ~5 degrees) -- but it seems to be on target now. For reasons I don't understand, it was firing the element even though it was clearly already above the target temp. The steak was still tasty with a quick sear afterward.













Test #2 underway. I ran a recirc in the HLT at 154F and then up to 180F with the pump running the entire time (~2+ hours). Then I brought the boil kettle up to boiling, also with the pump running (a bit of a torture test). Cavitation became a problem around boiling, but stopped when I re-oriented the pump vertical. In both cases, I had no problem with priming -- just use gravity. I should probably test with some restriction (e.g. valves) before brewing.




Almost 10oz of old hops being boiled...



Since the plumber never called me back, I went on a mission to plumb the sink Saturday. The process involved way too much crawling around under the house. The sink is from a local restaurant supply store, I picked it up on a discount for $399 + the sprayer + the faucet. The sink has a huge 24" x 24" tub -- very easy to fit the kettles inside. Backsplash is next on the list. As an aside, you can probably get away without a sprayer by just sticking your thumb over the end of the filling hose




I found some 'dish washer disconnects' at the local ace hardware. Not shown in the picture is a hose -> barb adapter that will give me an easy way to connect/disconnect my filling hose. 1/2" silicon fits over the end as is, but the disconnect makes it easier to remove.

__________________
bolts is offline

Reply With Quote Quick reply to this message
Old 08-27-2012, 07:21 AM   #59
bolts
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2009
Location: Portland, OR
Posts: 306
Liked 8 Times on 7 Posts
Likes Given: 3

Default Bill of Materials

I had great customer service from everyone I ordered the control panel parts from. Auber was quick to email, Locking Power Cords promptly fixed a wrong part, Pioneer fixed a few mistakes and ultimately made it right. Even Amazon took some returns of parts I no longer needed. The one exception to this was Stout Tanks -- and even then, John is a great guy in person, just difficult to get a stream of communication going. I'll elaborate in a review of the kettles.

I didn't spend a huge amount of time hunting for the best prices -- but I did try to find reasonable places and concentrate my orders in only a few places to reduce the shipping costs (i.e. I usually can't stand ebay). I was also able to pick up the wire, connectors, fasteners and some other misc parts locally.

The only part on this whole list I really didn't like was the relay socket. It has a bit of a cheap feel to it and it seems like the screw terminals are going to pull out of the body. On the good side, the wire was really nice. This sounds silly, but nice flexible wire with no memory is great to work with.

During the assembly I used a lot of star washers to keep things in place (or blue thread locker in a couple places). The star washers have a side effect of cutting into the base plate and heatsink to ground the fastener too.

https://www.dropbox.com/s/w1e8w9kr0okyuwp/Parts.xlsx

__________________
bolts is offline

Reply With Quote Quick reply to this message
Old 08-27-2012, 08:05 AM   #60
bolts
Feedback Score: 0 reviews
Recipes

Join Date: Sep 2009
Location: Portland, OR
Posts: 306
Liked 8 Times on 7 Posts
Likes Given: 3

Default What I would change...

There comes a point in a project where you stand back and review the work ... and then think of all the things you would tweak or change, and the good parts too. This is that list in no particular order.

Control Panel

The enclosure I used is a great size -- 16x16x12(D). The depth makes it trivial to make everything fit and the width/height make it pretty easy to stick your hands in the box and poke around. The depth has a second benefit also since it's mounted next to my kettles -- it stick out further making it easier to reach.

My layout was based on Kals' with a few tweaks. I'm planning on phasing some components over to Arduino control and that drove some of the layout decisions (the top right space for a keypad). The power switch clears the lock fine (I checked before cutting) -- but the tag doesn't fit .. oops. If I did it again, I'd probably move the power switch to the top right lined up with the yellow row -- seems to make more sense. I also may yet swap the water pump switch and alarm -- the lack of symmetry is bugging me

Label the wires and test connections as you go. Assembling it is easy if you're focused and following a diagram. However, once you get done it's just a big jumble of wires - I didn't label mine. I only made one trivial wiring mistake, but it could have been pretty painful to try and debug any errors (and unforgiving if things start frying). If you're probing inside with a multi-meter, make sure you have a steady hand --- or you really trust that GFCI. Lots of exposed ways to fry yourself.

I didn't add an emergency stop (The PJ style GFCI short is easy) -- eh. Maybe I should.

Get a good wire stripper and you must have a good crimper. I used a Klein stripper and the crimper I ordered worked great for all the red/blue/yellow crimps I used. This thing was night and day from other horrible methods I've tried I got my crimp terminals at home depot and matched them to the wire size and screw hole. As much as possible I used the ring version instead of spades so nothing can go flying if it gets loose. I think I used spades on all the switches/lights on the door -- everything else was rings.

I ran each wire and cut to length as needed keeping in mind the door and organizing it with zip ties. Don't be afraid to reroute, replace and recut wires. I did quite a few over as I built and again as I tidied it up. It came out better organized that way.

If you get the deluxe probe cables from Auber try asking for longer leads on the part in the panel that connects to the PID. I had to solder on new leads given the size of the box. Easy if you have the equipment, otherwise this would be difficult.

I realized after I had it together that replacing a broken component, like a relay, is going to be a nightmare. I'll have to pull most of the wiring and cut the zip ties to lift out the backplate. In hindsight (or if it ever comes apart) I should have either threaded holes in the back plate for mounting the parts or welded the nuts to the back. Neither of these an easy task. Which leads to...

I'll seriously consider a DIN rail mounted system if I build a version 2 someday. When I initially looked at the DIN route, I couldn't find any clear and concise information on what I needed and the parts seem to generally be quite a bit higher in cost. A DIN rail setup would make serviceability better and it would probably go together faster -- although honestly it wasn't that bad. It would also make it easier to tinker with the guts if desired.

I'm still debating the quality of the probe quick disconnects. They came from Auber, but the probes seem prone to poor connections. I've had more than a instances already where I had to jiggle the connector to get a reading (besides error) on PID. They seem decent, but something about them is giving me trouble.

I like the lighted switches a lot. More space for a logo

The Sink

I hate our crawl space. Hire a plumber. 'nuff said.


Tri-Clamp

Obviously, I took the tri-clamp route. I won't start a flame-war or start trolling, but I'm a convert and a fan. The cost and investment isn't trivial. However, who doesn't like 50 pounds of stainless bling.

The soft silicon seals better, but the harder materials are easier to connect. Hooking them up isn't hard, but it takes some coordination.

Now that I have a clue about TC hardware, I realize I could have used 1" everything (valves, elbows, tees, etc) instead of 1.5". It would save some cost, liquid deadspace, weight and bench space -- but it really doesn't matter in the grand scheme of things. The kettle outlets are 1" however -- so 1.5" is mostly pointless.

The bad -- how many clamps do you need? I mean really, I can barely carry the box of them and I'm still short.


The Bench

The bench came out nice. It's already apparent after a couple test runs that I need to add a lip in the back at least to contain spills. It's also going to get punished by the moisture and heat. The concrete top is still on my todo list once I decide if this is the right size and shape (20" x 60").

I'm going to need a whole lot more storage too. Hoses, clamps, gaskets, valves, etc etc.

Ventilation

If the ventilation guy would ever call me back I might get one....



Overall I'm looking forward to brewing on this system.

__________________
bolts is offline

Reply With Quote Quick reply to this message
