Default Immersion Chiller Question

Building a immersion chiller and I came across a post awhile back from a home brewer who built his chiller and posted pictures on this site. I ran a search and came up with over four hundred posts and after looking thru about 300 I gave up trying to find his post. So am writing to see if anyone can steer me to this particular post. His chiller was the copper coil shaped around a corny keg, he used copper wire to evenly space and tie each coil. He tied each coil on three sides and sweated the wires. I would like to do the same if I can find his post, can anyone help? Thanks.

__________________
IPAman is offline

Reply With Quote Quick reply to this message
Old 04-21-2009, 05:20 PM   #2
bull8042
I like 'em shaved
Feedback Score: 0 reviews

bull8042's Avatar
Recipes

Join Date: Jul 2008
Location: Fort Mill, SC
Posts: 10,279
Liked 444 Times on 443 Posts
Likes Given: 11

Default

Did it look like this?

__________________
"I brew with a water cooler and some part from the toilet." - JohnnyO

"I do gravity feed the last gallon or two through my Therminator, but I expect you could suck start a Volkswagen before you could suck start one of these. - GilaMinumBeer

"..... Bull was right." - TXCurtis
bull8042 is offline

Reply With Quote Quick reply to this message
Old 04-23-2009, 12:48 PM   #3
IPAman
Feedback Score: 0 reviews
Recipes

Join Date: Feb 2009
Location: Battle Creek, Michigan
Posts: 31
Default chiller

Yes, thanks for posting it.

__________________
IPAman is offline

Reply With Quote Quick reply to this message
Old 04-23-2009, 05:18 PM   #4
bull8042
I like 'em shaved
Feedback Score: 0 reviews

bull8042's Avatar
Recipes

Join Date: Jul 2008
Location: Fort Mill, SC
Posts: 10,279
Liked 444 Times on 443 Posts
Likes Given: 11

Default

Quote:
Originally Posted by IPAman View Post
Yes, thanks for posting it.
No problem. It sports 50' of 1/2" ID copper for the coil and all of the straight pieces are 5/8" OD pipe. Nothing really exotic, but I have a few more pics if you would like to see them.
__________________
"I brew with a water cooler and some part from the toilet." - JohnnyO

"I do gravity feed the last gallon or two through my Therminator, but I expect you could suck start a Volkswagen before you could suck start one of these. - GilaMinumBeer

"..... Bull was right." - TXCurtis
bull8042 is offline

Reply With Quote Quick reply to this message
Old 04-23-2009, 06:09 PM   #5
axr
Feedback Score: 0 reviews
Recipes

Join Date: Apr 2009
Location: West Orange, NJ
Posts: 115
Default

Quote:
Originally Posted by bull8042 View Post
No problem. It sports 50' of 1/2" ID copper for the coil and all of the straight pieces are 5/8" OD pipe. Nothing really exotic, but I have a few more pics if you would like to see them.
This chiller looks awesome! Can you post the other pics?
__________________
axr is offline

Reply With Quote Quick reply to this message
Old 04-23-2009, 07:25 PM   #6
bull8042
I like 'em shaved
Feedback Score: 0 reviews

bull8042's Avatar
Recipes

Join Date: Jul 2008
Location: Fort Mill, SC
Posts: 10,279
Liked 444 Times on 443 Posts
Likes Given: 11

Default

Here you go...








__________________
"I brew with a water cooler and some part from the toilet." - JohnnyO

"I do gravity feed the last gallon or two through my Therminator, but I expect you could suck start a Volkswagen before you could suck start one of these. - GilaMinumBeer

"..... Bull was right." - TXCurtis
bull8042 is offline

Reply With Quote Quick reply to this message
Old 04-23-2009, 07:33 PM   #7
WeizGuy
Feedback Score: 0 reviews
Recipes

Join Date: Apr 2009
Location: West Michigan
Posts: 9
Default

Inlet, outlet and a third for wort removal (inside line)?

__________________
WeizGuy is offline

Reply With Quote Quick reply to this message
Old 04-23-2009, 08:00 PM   #8
Boondoggie
Feedback Score: 0 reviews
Recipes

Join Date: Jul 2008
Location: Manchvegas, NH
Posts: 230
Liked 2 Times on 2 Posts

Default

I'm guessing the 3rd is for putting wort back IN.... draw it out thru a spigot, and pump it back thru that pipe, to get a whirpool effect?

__________________
Boondoggie is offline

Reply With Quote Quick reply to this message
Old 04-23-2009, 08:45 PM   #9
bull8042
I like 'em shaved
Feedback Score: 0 reviews

bull8042's Avatar
Recipes

Join Date: Jul 2008
Location: Fort Mill, SC
Posts: 10,279
Liked 444 Times on 443 Posts
Likes Given: 11

Default

Quote:
Originally Posted by Boondoggie View Post
I'm guessing the 3rd is for putting wort back IN.... draw it out thru a spigot, and pump it back thru that pipe, to get a whirpool effect?

That is exactly correct. I press-fitted a section of pipe in the end of the 45 so I could bend it, flatten it, shape it, etc without having to un-solder anything if the return flow didn't suit me.
__________________
"I brew with a water cooler and some part from the toilet." - JohnnyO

"I do gravity feed the last gallon or two through my Therminator, but I expect you could suck start a Volkswagen before you could suck start one of these. - GilaMinumBeer

"..... Bull was right." - TXCurtis
bull8042 is offline
